Dimensions of gear units
Type
∅
a1
∅
b1
b8 B B2 c1 c2
∅
dh
∅
Dh
Dha
∅
e1
f1 h H i2 le lh las lha m1
∅
s1
sm sas th uh
K1 160 110
j6
70 90 106 10 32.0 20
H7
40 ☐105 130 3.5 60 160 25.0 98.0 120 12 127.0 60 9 M6 M8 22.8 6
JS9
K1 160 110
j6
70 90 106 10 32.0 25
H7
40 ☐105 130 3.5 60 160 25.0 98.0 120 12 127.0 60 9 M10 M12 28.3 8
JS9
K1 160 110
j6
70 90 106 10 32.0 30
H7
40 ☐105 130 3.5 60 160 25.0 93.5 120 12 127.0 60 9 M10 M12 32.0 8
JS9
K2 200 130
j6
90 115 134 12 32.0 30
H7
45 ☐116 165 3.5 65 190 25.0 121.5 148 12 156.0 65 11 M10 M12 33.3 8
JS9
K3 200 130
j6
105 130 146 14 38.0 35
H7
50 ☐132 165 3.5 75 213 31.0 125.0 160 12 168.0 75 11 M12 M16 38.3 10
JS9
K4 250 180
j6
120 148 173 15 40.0 40
H7
55 ☐152 215 4.0 90 240 32.5 157.0 188 12 197.5 90 14 M16 M20 43.3 12
JS9
K5 250 180
j6
125 160 185 15 39.5 50
H7
65 ☐145 215 4.0 160 260 32.0 164.0 200 12 209.5 100 14 M16 M20 53.8 14
JS9
K6 300 230
j6
130 168 200 17 36.0 50
H7
70 ∅183 265 4.0 190 310 28.5 179.0 215 12 224.5 120 14 M16 M20 53.8 14
JS9
K7 350 250
h6
145 190 226 18 44.0 60
H7
85 ∅205 300 5.0 212 342 36.0 214.0 242 12 252.0 125 18 M20 M24 64.4 18
JS9
K8 400 300
h6
185 235 282 20 45.0 70
H7
100 ∅184 350 5.0 265 410 36.0 263.0 300 20 311.0 145 18 M20 M24 74.9 20
JS9
K9 450 350
h6
225 285 330 23 50.0 90
H7
120 ∅230 400 5.0 315 495 40.0 302.0 350 26 361.0 180 18 M24 M30 95.4 25
JS9
Dimensions of additional round flanges
Type
∅
a1
∅
b1
c1
∅
e1
f1
∅
s1
K1 140 95
j6
10 115 3.0 9
K2 160 110
j6
12 130 3.5 9
K3 160 110
j6
14 130 3.5 9
K3 250 180
j6
14 215 4.0 14
K8 350 250
h6
18 300 5.0 18
K8 450 350
h6
20 400 5.0 18
Motor adapter dimensions
Type c6 p10 w7 x2 y2 z7
K_MB23 140 59 102.9 58 64 57.5
K_MB33 161 59 115.4 58 64 71.0
K_MB43 194 59 134.9 58 64 93.5
Dimensions of motors
Type
☐
g
q1 w1 x0 z0
EZ402U 98 192.0 91.0 22 101.5
EZ404U 98 242.0 91.0 22 151.5
EZ501U 115 163.5 100.0 22 74.5
EZ502U 115 188.5 100.0 22 99.5
EZ503U 115 213.5 100.0 22 124.5
EZ505U 115 263.5 100.0 22 174.5
EZ701U 145 180.0 115.0 22 83.0
EZ702U 145 205.0 115.0 22 108.0
EZ703U 145 230.0 115.0 22 133.0
EZ705U 145 285.0 134.0 22 184.0
EZ803U 190 340.0 156.5 22 209.0
EZ805U 190 422.0 156.5 22 291.0
Dimensions of geared motors
Type MB23_EZ4 MB23_EZ5 MB33_EZ7 MB43_EZ8
a m n a m n a m n a m n
K102 ∅160 128 36.0 ∅160 128 36.0 – – – – – –
K202 ∅160 147 46.0 ∅160 147 46.0 ∅200 149 46.0 – – –
K302 ∅160 167 52.5 ∅160 167 52.5 ∅200 169 52.5 – – –
K402 ∅160 187 60.0 ∅160 187 60.0 ∅200 189 60.0 ∅250 192 60.0
K513 ∅160 172 15.0 ∅160 172 15.0 ∅200 174 15.0 ∅250 177 15.0
K613 ∅160 191 18.0 ∅160 191 18.0 ∅200 193 18.0 ∅250 196 18.0
K713 – – – – – – ∅200 221 20.0 ∅250 224 20.0
K813 – – – – – – ∅200 247 24.0 ∅250 249 24.0
K913 – – – – – – – – – ∅250 294 25.0
10 Khelical bevel geared motors 10.3 Dimensional drawings
