Stober PK - Page 333

Dimensions of gear units
Type a0
∅
a1
∅
b1
b3 b4 b5 b7 B B2 c1 c2
∅
dh
∅
Dh
Dha
∅
e1
f1 h
K1 115 160 110
j6
30 90 30 90 90 106 10 32.0 20
H7
40 ☐105 130 3.5 75
K1 115 160 110
j6
30 90 30 90 90 106 10 32.0 25
H7
40 ☐105 130 3.5 75
K1 115 160 110
j6
30 90 30 90 90 106 10 32.0 30
H7
40 ☐105 130 3.5 75
K5 200 250 180
j6
40 140 100 140 160 185 15 39.5 50
H7
65 ☐145 215 4.0 190
K6 210 300 230
j6
50 160 110 160 168 200 17 36.0 50
H7
70 ∅183 265 4.0 220
K7 241 350 250
h6
55 180 125 180 190 226 18 44.0 60
H7
85 ∅205 300 5.0 250
K8 300 400 300
h6
75 240 165 240 235 282 20 45.0 70
H7
100 ∅184 350 5.0 310
K9 360 450 350
h6
95 280 185 280 285 330 23 50.0 90
H7
120 ∅230 400 5.0 365
Dimensions of gear units
Type H i2 le lh las lha m1 n2 n3 n4 n5
∅
s
∅
s1
sm sas th uh
K1 175 25.0 98.0 120 12 127.0 75 30 13 140 15 9.0 9 M6 M8 22.8 6
JS9
K1 175 25.0 98.0 120 12 127.0 75 30 13 140 15 9.0 9 M10 M12 28.3 8
JS9
K1 175 25.0 93.5 120 12 127.0 75 30 13 140 15 9.0 9 M10 M12 32.0 8
JS9
K5 290 32.0 164.0 200 12 209.5 130 60 27 240 30 18.0 14 M16 M20 53.8 14
JS9
K6 340 28.5 179.0 215 12 224.5 150 65 27 250 30 18.5 14 M16 M20 53.8 14
JS9
K7 380 36.0 214.0 242 12 252.0 163 70 35 290 38 23.0 18 M20 M24 64.4 18
JS9
K8 455 36.0 263.0 300 20 311.0 190 85 41 360 45 27.0 18 M20 M24 74.9 20
JS9
K9 545 40.0 302.0 350 26 361.0 230 95 46 430 50 31.0 18 M24 M30 95.4 25
JS9
Dimensions of additional round flanges
Type
∅
a1
∅
b1
c1
∅
e1
f1
∅
s1
K1 140 95
j6
10 115 3 9
K8 350 250
h6
18 300 5 18
K8 450 350
h6
20 400 5 18
Motor adapter dimensions
Type c6 p10 w7 x2 y2 z7
K_MB23 140 59 102.9 58 64 57.5
K_MB33 161 59 115.4 58 64 71.0
K_MB43 194 59 134.9 58 64 93.5
Dimensions of motors
Type
☐
g
q1 w1 x0 z0
EZ402U 98 192.0 91.0 22 101.5
EZ404U 98 242.0 91.0 22 151.5
EZ501U 115 163.5 100.0 22 74.5
EZ502U 115 188.5 100.0 22 99.5
EZ503U 115 213.5 100.0 22 124.5
EZ505U 115 263.5 100.0 22 174.5
EZ701U 145 180.0 115.0 22 83.0
EZ702U 145 205.0 115.0 22 108.0
EZ703U 145 230.0 115.0 22 133.0
EZ705U 145 285.0 134.0 22 184.0
EZ803U 190 340.0 156.5 22 209.0
EZ805U 190 422.0 156.5 22 291.0
Dimensions of geared motors
Type MB23_EZ4 MB23_EZ5 MB33_EZ7 MB43_EZ8
a m n a m n a m n a m n
K102 ∅160 128 36.0 ∅160 128 36.0 – – – – – –
K513 ∅160 172 15.0 ∅160 172 15.0 ∅200 174 15.0 ∅250 177 15.0
K613 ∅160 191 18.0 ∅160 191 18.0 ∅200 193 18.0 ∅250 196 18.0
K713 – – – – – – ∅200 221 20.0 ∅250 224 20.0
K813 – – – – – – ∅200 247 24.0 ∅250 249 24.0
K913 – – – – – – – – – ∅250 294 25.0
10 Khelical bevel geared motors 10.3 Dimensional drawings
333
