Dimensions of gear units
Type
∅
a1
∅
b1
b8 B B2 c1 c2
∅
ds
∅
ds1
∅
ds2
∅
dss
∅
Ds
∅
Dsa
∅
Dss
∅
e1
f1 h H i2 ls lsa m1 m2 m3 m4 m5
∅
s1
K1 160 110
j6
70 90 106 10 32.0 25
h9
25
h9
H7
25.5 30 40 80.0 60 130 3.5 60 160 25.0 149 163 60 20 34 25 29 9
K2 200 130
j6
90 115 134 12 32.0 30
h9
30
h9
H7
30.5 36 45 88.0 72 165 3.5 65 190 25.0 178 193 65 25 39 30 34 11
K3 200 130
j6
105 130 146 14 38.0 35
h9
35
h9
H7
35.5 44 50 101.0 80 165 3.5 75 213 31.0 190 206 75 30 39 35 34 11
K4 250 180
j6
120 148 173 15 40.0 40
h9
40
h9
H7
40.5 50 55 114.0 88 215 4.0 90 240 32.5 220 243 90 40 39 45 34 14
K5 250 180
j6
125 160 185 15 39.5 50
h9
50
h9
H7
50.5 62 65 116.0 106 215 4.0 160 260 32.0 237 254 100 40 44 45 39 14
K6 300 230
j6
130 168 200 17 36.0 50
h9
50
h9
H7
50.5 62 70 128.0 106 265 4.0 190 310 28.5 254 276 120 40 45 45 40 14
K7 350 250
h6
145 190 226 18 44.0 60
h6
60
h6
H7
62.0 75 85 161.5 138 300 5.0 212 342 36.0 278 314 125 40 45 45 40 18
K8 400 300
h6
185 235 282 20 45.0 70
h6
70
h6
H7
72.0 90 100 193.0 155 350 5.0 265 410 36.0 352 378 145 50 60 60 50 18
K9 450 350
h6
225 285 330 23 50.0 90
h6
90
h6
H7
92.0 120 120 244.0 200 400 5.0 315 495 40.0 418 428 180 60 70 70 60 18
Dimensions of additional round flanges
Type
∅
a1
∅
b1
c1
∅
e1
f1
∅
s1
K1 140 95
j6
10 115 3.0 9
K2 160 110
j6
12 130 3.5 9
K3 160 110
j6
14 130 3.5 9
K3 250 180
j6
14 215 4.0 14
K8 350 250
h6
18 300 5.0 18
K8 450 350
h6
20 400 5.0 18
Motor adapter dimensions
Type c6 p10 w7 x2 y2 z7
K_MB23 140 59 102.9 58 64 57.5
K_MB33 161 59 115.4 58 64 71.0
K_MB43 194 59 134.9 58 64 93.5
Dimensions of motors
Type
☐
g
q1 w1 x0 z0
EZ402U 98 192.0 91.0 22 101.5
EZ404U 98 242.0 91.0 22 151.5
EZ501U 115 163.5 100.0 22 74.5
EZ502U 115 188.5 100.0 22 99.5
EZ503U 115 213.5 100.0 22 124.5
EZ505U 115 263.5 100.0 22 174.5
EZ701U 145 180.0 115.0 22 83.0
EZ702U 145 205.0 115.0 22 108.0
EZ703U 145 230.0 115.0 22 133.0
EZ705U 145 285.0 134.0 22 184.0
EZ803U 190 340.0 156.5 22 209.0
EZ805U 190 422.0 156.5 22 291.0
Dimensions of geared motors
Type MB23_EZ4 MB23_EZ5 MB33_EZ7 MB43_EZ8
a m n a m n a m n a m n
K102 ∅160 128 36.0 ∅160 128 36.0 – – – – – –
K202 ∅160 147 46.0 ∅160 147 46.0 ∅200 149 46.0 – – –
K302 ∅160 167 52.5 ∅160 167 52.5 ∅200 169 52.5 – – –
K402 ∅160 187 60.0 ∅160 187 60.0 ∅200 189 60.0 ∅250 192 60.0
K513 ∅160 172 15.0 ∅160 172 15.0 ∅200 174 15.0 ∅250 177 15.0
K613 ∅160 191 18.0 ∅160 191 18.0 ∅200 193 18.0 ∅250 196 18.0
K713 – – – – – – ∅200 221 20.0 ∅250 224 20.0
K813 – – – – – – ∅200 247 24.0 ∅250 249 24.0
K913 – – – – – – – – – ∅250 294 25.0
10 Khelical bevel geared motors 10.3 Dimensional drawings
