Dimensions of gear units
Type a0
∅
a1
∅
b1
b3 b4 b5 b7 B B2 c1
∅
ds
∅
ds1
∅
ds2
∅
dss
∅
Ds
∅
Dsa
∅
Dss
K1 115 160 110
j6
30 90 30 90 90 106 10 25
h9
25
h9
H7
25.5 30 40 80.0 60
K5 200 250 180
j6
40 140 100 140 160 185 15 50
h9
50
h9
H7
50.5 62 65 116.0 106
K6 210 300 230
j6
50 160 110 160 168 200 17 50
h9
50
h9
H7
50.5 62 70 128.0 106
K7 241 350 250
h6
55 180 125 180 190 226 18 60
h6
60
h6
H7
62.0 75 85 161.5 138
K8 300 400 300
h6
75 240 165 240 235 282 20 70
h6
70
h6
H7
72.0 90 100 193.0 155
K9 360 450 350
h6
95 280 185 280 285 330 23 90
h6
90
h6
H7
92.0 120 120 244.0 200
Dimensions of gear units
Type
∅
e1
f1 h H i2 ls lsa m1 m2 m3 m4 m5 n2 n3 n4 n5
∅
s
∅
s1
K1 130 3.5 75 175 25.0 149 163 75 20 34 25 29 30 13 140 15 9.0 9
K5 215 4.0 190 290 32.0 237 254 130 40 44 45 39 60 27 240 30 18.0 14
K6 265 4.0 220 340 28.5 254 276 150 40 45 45 40 65 27 250 30 18.5 14
K7 300 5.0 250 380 36.0 278 314 163 40 45 45 40 70 35 290 38 23.0 18
K8 350 5.0 310 455 36.0 352 378 190 50 60 60 50 85 41 360 45 27.0 18
K9 400 5.0 365 545 40.0 418 428 230 60 70 70 60 95 46 430 50 31.0 18
Dimensions of additional round flanges
Type
∅
a1
∅
b1
c1
∅
e1
f1
∅
s1
K1 140 95
j6
10 115 3 9
K8 350 250
h6
18 300 5 18
K8 450 350
h6
20 400 5 18
Motor adapter dimensions
Type c6 p10 w7 x2 y2 z7
K_MB23 140 59 102.9 58 64 57.5
K_MB33 161 59 115.4 58 64 71.0
K_MB43 194 59 134.9 58 64 93.5
Dimensions of motors
Type
☐
g
q1 w1 x0 z0
EZ402U 98 192.0 91.0 22 101.5
EZ404U 98 242.0 91.0 22 151.5
EZ501U 115 163.5 100.0 22 74.5
EZ502U 115 188.5 100.0 22 99.5
EZ503U 115 213.5 100.0 22 124.5
EZ505U 115 263.5 100.0 22 174.5
EZ701U 145 180.0 115.0 22 83.0
EZ702U 145 205.0 115.0 22 108.0
EZ703U 145 230.0 115.0 22 133.0
EZ705U 145 285.0 134.0 22 184.0
EZ803U 190 340.0 156.5 22 209.0
EZ805U 190 422.0 156.5 22 291.0
Dimensions of geared motors
Type MB23_EZ4 MB23_EZ5 MB33_EZ7 MB43_EZ8
a m n a m n a m n a m n
K102 ∅160 128 36.0 ∅160 128 36.0 – – – – – –
K513 ∅160 172 15.0 ∅160 172 15.0 ∅200 174 15.0 ∅250 177 15.0
K613 ∅160 191 18.0 ∅160 191 18.0 ∅200 193 18.0 ∅250 196 18.0
K713 – – – – – – ∅200 221 20.0 ∅250 224 20.0
K813 – – – – – – ∅200 247 24.0 ∅250 249 24.0
K913 – – – – – – – – – ∅250 294 25.0
