Stober PK - Page 349

Dimensions of gear units
Type
∅
a1
∅
b1
b8 B B2 c1 c2
∅
d
∅
e1
f1 h H i2 l l1 m1
∅
s1
s2 t u
K1 160 110
j6
70 90 106 10 32.0 25
k6
130 3.5 60 160 30.0 50 4 60 9 M10 28.0 A8×7×40
K2 200 130
j6
90 115 134 12 32.0 30
k6
165 3.5 65 190 36.0 60 4 65 11 M10 33.0 A8×7×50
K3 200 130
j6
105 130 146 14 38.0 30
k6
165 3.5 75 213 31.0 60 4 75 11 M10 33.0 A8×7×50
K4 250 180
j6
120 148 173 15 40.0 40
k6
215 4.0 90 240 49.5 80 4 90 14 M16 43.0 A12×8×70
K5 250 180
j6
125 160 185 15 39.5 45
k6
215 4.0 160 260 90.0 90 4 100 14 M16 48.5 A14×9×80
K6 300 230
j6
130 168 200 17 36.0 50
k6
265 4.0 190 310 100.0 100 4 120 14 M16 53.5 A14×9×90
K7 350 250
h6
145 190 226 18 44.0 60
m6
300 5.0 212 342 120.0 120 4 125 18 M20 64.0 A18×11×110
K8 400 300
h6
185 235 282 20 45.0 70
m6
350 5.0 265 410 140.0 140 5 145 18 M20 74.5 A20×12×125
K9 450 350
h6
225 285 330 23 50.0 90
m6
400 5.0 315 495 170.0 170 8 180 18 M24 95.0 A25×14×140
Dimensions of additional round flanges
Type
∅
a1
∅
b1
c1
∅
e1
f1
∅
s1
K1 140 95
j6
10 115 3.0 9
K2 160 110
j6
12 130 3.5 9
K3 160 110
j6
14 130 3.5 9
K3 250 180
j6
14 215 4.0 14
K8 350 250
h6
18 300 5.0 18
K8 450 350
h6
20 400 5.0 18
Motor adapter dimensions
Type c6 p10 w7 x2 y2 z7
K_MB23 140 59 102.9 58 64 57.5
K_MB33 161 59 115.4 58 64 71.0
K_MB43 194 59 134.9 58 64 93.5
Dimensions of motors
Type
☐
g
q1 w1 x0 z0
EZ402U 98 192.0 91.0 22 101.5
EZ404U 98 242.0 91.0 22 151.5
EZ501U 115 163.5 100.0 22 74.5
EZ502U 115 188.5 100.0 22 99.5
EZ503U 115 213.5 100.0 22 124.5
EZ505U 115 263.5 100.0 22 174.5
EZ701U 145 180.0 115.0 22 83.0
EZ702U 145 205.0 115.0 22 108.0
EZ703U 145 230.0 115.0 22 133.0
EZ705U 145 285.0 134.0 22 184.0
EZ803U 190 340.0 156.5 22 209.0
EZ805U 190 422.0 156.5 22 291.0
Dimensions of geared motors
Type MB23_EZ4 MB23_EZ5 MB33_EZ7 MB43_EZ8
a m n a m n a m n a m n
K102 ∅160 128 36.0 ∅160 128 36.0 – – – – – –
K202 ∅160 147 46.0 ∅160 147 46.0 ∅200 149 46.0 – – –
K302 ∅160 167 52.5 ∅160 167 52.5 ∅200 169 52.5 – – –
K402 ∅160 187 60.0 ∅160 187 60.0 ∅200 189 60.0 ∅250 192 60.0
K513 ∅160 172 15.0 ∅160 172 15.0 ∅200 174 15.0 ∅250 177 15.0
K613 ∅160 191 18.0 ∅160 191 18.0 ∅200 193 18.0 ∅250 196 18.0
K713 – – – – – – ∅200 221 20.0 ∅250 224 20.0
K813 – – – – – – ∅200 247 24.0 ∅250 249 24.0
K913 – – – – – – – – – ∅250 294 25.0
10 Khelical bevel geared motors 10.3 Dimensional drawings
349
