Stober PK - Page 45

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PH7 (n
1N
= 3000 rpm, M
2acc,max
= 870 Nm)
600 102 145 8.8 3.8 PH731_0050 MB33 EZ705U 480 480 907 5.000 5/1 32 32 2200 4000 68 208 45
600 102 145 8.8 3.8 PH731_0050 MB33 EZ705U 480 480 907 5.000 5/1 45 32 2200 4000 68 208 45
750 82 116 12 4.7 PH731_0040 MB33 EZ705U 384 384 726 4.000 4/1 16 32 1900 4000 70 243 45
750 82 116 12 4.7 PH731_0040 MB33 EZ705U 384 384 726 4.000 4/1 24 32 1900 4000 70 243 45
750 82 116 12 4.7 PH731_0040 MB33 EZ705U 384 384 726 4.000 4/1 32 32 1900 4000 70 243 45
750 82 116 12 4.7 PH731_0040 MB33 EZ705U 384 384 726 4.000 4/1 45 32 1900 4000 70 243 45
PH8 (n
1N
= 2000 rpm, M
2acc,max
= 1390 Nm)
200 420 635 4.2 1.8 PH831_0100 MB43 EZ805U 1392 1392 2784 10.00 10/1 50 115 2200 3000 262 344 106
286 294 444 5.0 3.4 PH831_0070 MB43 EZ805U 1378 1378 2258 7.000 7/1 50 115 2000 3000 266 463 106
400 210 317 7.7 4.6 PH831_0050 MB43 EZ805U 984 984 1613 5.000 5/1 50 115 1600 3000 274 604 106
500 168 254 13 4.6 PH831_0040 MB43 EZ805U 787 787 1290 4.000 4/1 50 115 1400 3000 284 620 106
PH8 (n
1N
= 3000 rpm, M
2acc,max
= 2100 Nm)
60 344 386 0.7 3.7 PH832_0500 MB33 EZ701U 930 930 4200 50.00 50/1 16 15 3000 4000 38 491 58
60 558 670 1.1 2.3 PH832_0500 MB33 EZ702U 1907 1907 4200 50.00 50/1 16 15 3000 4000 43 491 60
75 275 309 1.0 3.7 PH832_0400 MB33 EZ701U 744 744 3840 40.00 40/1 16 15 3000 4000 39 453 58
75 446 536 1.6 2.3 PH832_0400 MB33 EZ702U 1525 1525 3840 40.00 40/1 16 15 3000 4000 45 453 60
86 391 469 1.4 3.2 PH832_0350 MB33 EZ702U 1335 1335 4200 35.00 35/1 16 15 3000 4000 43 511 60
86 391 469 1.4 3.2 PH832_0350 MB33 EZ702U 1335 1335 4200 35.00 35/1 24 15 3000 4000 43 511 60
86 391 469 1.4 3.2 PH832_0350 MB33 EZ702U 1335 1335 4200 35.00 35/1 32 15 3000 4000 43 511 60
86 537 677 1.9 2.3 PH832_0350 MB33 EZ703U 2100 2116 4200 35.00 35/1 16 32 3000 4000 55 511 63
86 693 983 2.4 1.8 PH832_0350 MB33 EZ705U 2100 2300 4200 35.00 35/1 16 32 3000 4000 68 511 69
107 312 375 1.9 3.2 PH832_0280 MB33 EZ702U 1068 1068 4000 28.00 28/1 16 15 3000 4000 45 480 60
107 312 375 1.9 3.2 PH832_0280 MB33 EZ702U 1068 1068 4000 28.00 28/1 24 15 3000 4000 45 480 60
107 312 375 1.9 3.2 PH832_0280 MB33 EZ702U 1068 1068 4000 28.00 28/1 32 15 3000 4000 45 480 60
107 430 542 2.6 2.3 PH832_0280 MB33 EZ703U 1693 1693 4000 28.00 28/1 16 32 3000 4000 57 480 63
107 555 786 3.4 1.8 PH832_0280 MB33 EZ705U 2000 2000 4000 28.00 28/1 16 32 3000 4000 69 480 69
120 279 335 1.6 4.5 PH832_0250 MB33 EZ702U 953 953 4200 25.00 25/1 16 15 2700 4000 44 521 60
120 279 335 1.6 4.5 PH832_0250 MB33 EZ702U 953 953 4200 25.00 25/1 24 15 2700 4000 44 521 60
120 279 335 1.6 4.5 PH832_0250 MB33 EZ702U 953 953 4200 25.00 25/1 32 15 2700 4000 44 521 60
120 279 335 1.6 4.5 PH832_0250 MB33 EZ702U 953 953 4200 25.00 25/1 45 15 2700 4000 44 521 60
120 384 484 2.2 3.3 PH832_0250 MB33 EZ703U 1511 1511 4200 25.00 25/1 16 32 2700 4000 55 521 63
120 384 484 2.2 3.3 PH832_0250 MB33 EZ703U 1511 1511 4200 25.00 25/1 24 32 2700 4000 55 521 63
120 384 484 2.2 3.3 PH832_0250 MB33 EZ703U 1511 1511 4200 25.00 25/1 32 32 2700 4000 55 521 63
120 495 702 2.9 2.5 PH832_0250 MB33 EZ705U 2100 2300 4200 25.00 25/1 16 32 2700 4000 68 521 69
120 495 702 2.9 2.5 PH832_0250 MB33 EZ705U 2100 2300 4200 25.00 25/1 24 32 2700 4000 68 521 69
120 495 702 2.9 2.5 PH832_0250 MB33 EZ705U 2100 2300 4200 25.00 25/1 32 32 2700 4000 68 521 69
150 307 387 2.5 4.1 PH832_0200 MB33 EZ703U 1209 1209 3515 20.00 20/1 16 32 2500 4000 56 526 63
150 307 387 2.5 4.1 PH832_0200 MB33 EZ703U 1209 1209 3515 20.00 20/1 24 32 2500 4000 56 526 63
150 307 387 2.5 4.1 PH832_0200 MB33 EZ703U 1209 1209 3515 20.00 20/1 32 32 2500 4000 56 526 63
150 307 387 2.5 4.1 PH832_0200 MB33 EZ703U 1209 1209 3515 20.00 20/1 45 32 2500 4000 56 526 63
150 396 562 3.2 3.2 PH832_0200 MB33 EZ705U 1860 1860 3515 20.00 20/1 16 32 2500 4000 68 526 69
150 396 562 3.2 3.2 PH832_0200 MB33 EZ705U 1860 1860 3515 20.00 20/1 24 32 2500 4000 68 526 69
150 396 562 3.2 3.2 PH832_0200 MB33 EZ705U 1860 1860 3515 20.00 20/1 32 32 2500 4000 68 526 69
150 396 562 3.2 3.2 PH832_0200 MB33 EZ705U 1860 1860 3515 20.00 20/1 45 32 2500 4000 68 526 69
188 246 310 3.5 4.1 PH832_0160 MB33 EZ703U 967 967 2812 16.00 16/1 16 32 2500 4000 58 501 63
188 246 310 3.5 4.1 PH832_0160 MB33 EZ703U 967 967 2812 16.00 16/1 24 32 2500 4000 58 501 63
188 246 310 3.5 4.1 PH832_0160 MB33 EZ703U 967 967 2812 16.00 16/1 32 32 2500 4000 58 501 63
188 246 310 3.5 4.1 PH832_0160 MB33 EZ703U 967 967 2812 16.00 16/1 45 32 2500 4000 58 501 63
188 317 449 4.5 3.2 PH832_0160 MB33 EZ705U 1488 1488 2812 16.00 16/1 16 32 2500 4000 70 501 69
188 317 449 4.5 3.2 PH832_0160 MB33 EZ705U 1488 1488 2812 16.00 16/1 24 32 2500 4000 70 501 69
188 317 449 4.5 3.2 PH832_0160 MB33 EZ705U 1488 1488 2812 16.00 16/1 32 32 2500 4000 70 501 69
188 317 449 4.5 3.2 PH832_0160 MB33 EZ705U 1488 1488 2812 16.00 16/1 45 32 2500 4000 70 501 69
300 255 463 2.9 2.6 PH831_0100 MB43 EZ803U 1392 1392 2784 10.00 10/1 50 65 2200 3000 173 344 90
300 255 463 2.9 2.6 PH831_0100 MB43 EZ803U 1392 1392 2784 10.00 10/1 72 65 2200 3000 173 344 90
300 255 463 2.9 2.6 PH831_0100 MB43 EZ803U 1392 1392 2784 10.00 10/1 100 65 2200 3000 173 344 90
429 179 324 3.5 4.9 PH831_0070 MB43 EZ803U 974 974 2258 7.000 7/1 50 65 2000 3000 178 463 90
429 179 324 3.5 4.9 PH831_0070 MB43 EZ803U 974 974 2258 7.000 7/1 72 65 2000 3000 178 463 90
429 179 324 3.5 4.9 PH831_0070 MB43 EZ803U 974 974 2258 7.000 7/1 100 65 2000 3000 178 463 90
3 PHplanetary geared motors 3.2 Selection tables
