Stober PK - Page 66

n
2N
M
2N
M
2,0
a
th
S Type M
2acc
M
2accHT
M
2NOT
i i
exakt
M
1Bstat
M
Bstat
n
1maxDB
n
1maxZB
J
1
C
2
m
[rpm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [Nm] [rpm] [rpm] [kgcm²] [Nm/ [kg]
arcmin]
PHQ8 (n
1N
= 3000 rpm, M
2acc,max
= 2560 Nm)
55 614 737 0.8 2.8 PHQ832_0550 MB33 EZ702U 2097 2097 5087 55.00 55/1 16 15 3000 4000 42 670 61
78 430 516 1.0 4.0 PHQ832_0390 MB33 EZ702U 1468 1468 5087 38.50 77/2 16 15 3000 4000 42 701 61
78 430 516 1.0 4.0 PHQ832_0390 MB33 EZ702U 1468 1468 5087 38.50 77/2 24 15 3000 4000 42 701 61
78 430 516 1.0 4.0 PHQ832_0390 MB33 EZ702U 1468 1468 5087 38.50 77/2 32 15 3000 4000 42 701 61
109 422 532 1.6 4.0 PHQ832_0280 MB33 EZ703U 1662 1662 4834 27.50 55/2 16 32 2700 4000 55 715 64
109 422 532 1.6 4.0 PHQ832_0280 MB33 EZ703U 1662 1662 4834 27.50 55/2 24 32 2700 4000 55 715 64
109 422 532 1.6 4.0 PHQ832_0280 MB33 EZ703U 1662 1662 4834 27.50 55/2 32 32 2700 4000 55 715 64
109 545 772 2.0 3.1 PHQ832_0280 MB33 EZ705U 2558 2558 4834 27.50 55/2 16 32 2700 4000 68 715 69
109 545 772 2.0 3.1 PHQ832_0280 MB33 EZ705U 2558 2558 4834 27.50 55/2 24 32 2700 4000 68 715 69
109 545 772 2.0 3.1 PHQ832_0280 MB33 EZ705U 2558 2558 4834 27.50 55/2 32 32 2700 4000 68 715 69
136 436 618 2.3 3.9 PHQ832_0220 MB33 EZ705U 2046 2046 3867 22.00 22/1 16 32 2500 4000 69 720 69
136 436 618 2.3 3.9 PHQ832_0220 MB33 EZ705U 2046 2046 3867 22.00 22/1 24 32 2500 4000 69 720 69
136 436 618 2.3 3.9 PHQ832_0220 MB33 EZ705U 2046 2046 3867 22.00 22/1 32 32 2500 4000 69 720 69
136 436 618 2.3 3.9 PHQ832_0220 MB33 EZ705U 2046 2046 3867 22.00 22/1 45 32 2500 4000 69 720 69
4.2 Selection tables 4 PHQplanetary geared motors
66
