V560 Series High Performance Closed-Loop Vector Inverter User manual
11.1.5 BRIEF INTRODUCTION OF FUNCTIONS
The Modbus functional codes supported by V560 are listed below:
Function
Code
(Hexadecimal)
Description of Functions
Read coil status 0x01
Read coil status by digit. Each digit for the controlling character is
mapped to coil 0~15 respectively.
Read discrete input
status
0x02
Read discrete input status. Each digit for the status character is
mapped to coil 0~15 respectively.
Read multiple hold
registers
0x03
Read multiple hold registers. It can read all the application parameters,
status parameters, controlling characters, status characters and
setting values of V560.
Read multiple input
registers
0x04
Read multiple input registers. The address for analog input register
starts from 0x1200.
Enforce single coil 0x05
Perform writing action for a single output digit. Each digit for the
controlling character is mapped to coil 1~16 respectively.
Write to a single hold
register
0x06
Perform writing action for a single hold register. All the parameters,
controlling characters, status characters and setting values of V560
are mapped to the hold register.
Query for the anomaly
status
0x07
Query for the anomaly status information. In V560, the failure
information of the frequency inverter can be queried.
Failure diagnosis 0x08
Execute field diagnosis for the bus failure. Support the sub-codes, like
querying (0x00), rebooting (0x01), monitoring (0x04) and
zero-clearing(0x0A) etc.
Enforce multiple coils 0x0F
Perform writing action for multiple output digits respectively. Each digit
for the controlling character is mapped to coil 1~16 respectively.
Write to multiple hold
registers
0x10
Perform writing action for multiple hold registers. All the parameters,
controlling characters, status characters and setting values of V560
are also mapped to the hold register.
Read/write to multiple
hold registers
0x17
This function equals to combining 0x03 and 0x10 into a new
command.
11.1.6 ACCESS ADDRESS SUMMARY
V560 Access Address
Functional Codes Supported
(Hexadecimal)
Controlling digit
Multi-purpose terminal output
Relay output
Coil (0x1000-0x1100)
0x01- Read coil status
0x05- Enforce single coil
0x0F- Enforce multiple coils
Multi-purpose terminal input for
status digit
Discrete input (0x1100-0x1200) 0x02- Read input status
Analog input Input register (0x1200-0x1300) 0x04- Read input register
Application parameters
Status parameters
Controlling characters, Status
characters
Setting values
Mapping status parameters
Mapping application parameters
Hold registers (application
parameter area, status parameter
area, 0x1300-0x1400)
0x03- Read multiple registers
0x06- Write to a single register
0x10- Write to multiple registers
0x17- Read/write to multiple registers
For detailed address distribution, please refer to below section of Modbus detailed address-finding
distribution.
