Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
80
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
1: Start and stop command linked
2: Start-stop/jog linked
3: Start-stop/jog/excitation linked
4: Start-stop/jog/excitation/DC bind-type
brake/DC braking linked
X _ _ _: linkage set choice
0: Unit digit of the parameter confirm
1: The input of external terminal
(function No.39)
FA.2.26
Linkage setting
proportion coefficient
0.010~10.000 0.001 1.000
FA.2.27
Fine adjustment source
for linkage proportion
coefficient
0: No fine adjustment
1: Analog inputAI1
2: Analog inputAI2
3: Analog inputAI3
1 0
FA.2.28
Slave device offset
frequency/ Revolution
0: No offset
1: Determined by frequency setting
source 1
2: Determined by frequency setting
source 2
1 0
FA.2.29
Linkage balancing
function
0: Void
1: Current balancing
2: Torque balancing
3: Power balancing
4: Position synchronous balancing
1 0
FA.2.30 Linkage balancing gain 0.001~10.000 0.001 1.000
FA.2.31
Amplitude limiting of
position synchronous
balancing
0.10~10.00Hz — 1.00
FA.2.32 Reserved — — —
6.2.43 EXPANSION MULTIFUNCTIONAL INPUT TERMINAL
(EDI1~ EDI8)/ Effective after Connecting Expanding Accessories
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
Fb.0.00
Expand multifunctional
input terminal EDI1
0~96 1 0 ×
Fb.0.01
Expand multifunctional
input terminal EDI2
0~96 1 0 ×
Fb.0.02
Expand multifunctional
input terminal EDI3
0~96 1 0 ×
Fb.0.03
Expand multifunctional
input terminal EDI4
0~96 1 0 ×
Fb.0.04
Expand multifunctional
input terminal EDI5
0~96 1 0 ×
Fb.0.05
Expand multifunctional
input terminal EDI6
0~96 1 0 ×
