Sunfar V560 Series User Manual

8 Product Introduction
V560 Series High Performance Closed-Loop Vector Inverter User Manual
Model
Universal load mode Steady light load mode
Rated
capacity
(KVA)
Rated
current
(A)
Adaptive
motor
(KW)
Rated
capacity
(KVA)
Rated
current
(A)
Adaptive
motor
(KW)
V560-4T2000G/4T2200P 253 385 200 276 420 220
V560-4T2200G/4T2500P 276 420 220 313 475 250
V560-4T2500G/4T2800P 313 475 250 352 535 280
V560-4T2800G/4T3150P 352 535 280 395 600 315
V560-4T3150G/4T3500P 395 600 315 424 645 350
V560-4T3500G/4T4000P 428 650 350 480 730 400
V560-4T4000G/4T4500P 480 730 400 527 800 450
V560-4T4500G/4T5000P 527 800 450 592 900 500
V560-4T5000G/4T5600P 592 900 500 658 1000 560
V560-4T5600G/4T6300P 658 1000 560 737 1120 630
V560-4T6300G/4T7000P 737 1120 630 823 1250 700
2.4 PRODUCT TECHNICAL INDEX AND SPECIFICATIONS
Input
Output
Rated voltage
frequency
Three phase(4T# series) 380V 50/60Hz
Output voltage 4T# series: 0~380 V
Output frequency
Low frequency mode：0.0~300.00Hz；
High frequency mode：0.0~2000.0Hz.
Digital input
Standard configuration: 6-circuit digital input (DI), extensible to
16-circuit (optional extension components)
Digital output Standard configuration: 2-circuit digital output (DO)
Pulse in and out
0~100.0KHz pulse input, can receive OC or 0~24V level signal
(optional)
Pulse output
0 -100.0KHz pulse output(optional), PWM output mode can be
selected to extend analog output terminal.
Analog input
Standard configuration: 0~10V voltage intput (AI1);
0~20mA current input (AI2)
Standard IO board: -10V~10V voltage input
Analog output
Two-circuit 0-10V analog output signal
(can be set to 0~10V current output mode)
Contact output
Standard one group of AC 250V/2A normally open and closed
contacts, extensible 1-6 groups normally open and closed contacts
Control
Characteristics
Control Mode
Closed-loop vector
control
Open-loop vector
control
V/F control
Starting torque 0 speed 200% 0 speed 180% 0 speed 180%
Speed adjustable
range
1 : 1000 1 : 200 1 : 100
Steady speed
precision
±0.02% ±0.2% ±0.5%
Torque control
precision
±5% ±5% --
