V560 Series High Performance Closed-Loop Vector Inverter User Manual
81
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
Fb.0.06
Expand multifunctional
input terminal EDI7
0~96 1 0 ×
Fb.0.07
Expand multifunctional
input terminal EDI8
0~96 1 0 ×
Fb.0.08
Expand multifunctional
terminal filtering time
1~50ms 1 5ms
Fb.0.09
Expand multi function
input terminal active
level
_ _ _ X: EDI1~EDI4 terminal
0~F: 4-bit binary system, bit=0 power-on
effective, 1 Disconnection Effective LED
_ _ X _: EDI5~EDI8 terminal
The same as above
_ X _ _: Reserved
X _ _ _: Reserved
1 0000 ×
6.2.44 EXPANSION MULTIFUNCTIONAL OUTPUT TERMINAL
(ED01/ ERO1~ ED04/ ERO4)/ Effective after Connecting Expanding Accessories
Function
Code
Name
Setting Range and
Description
Minimum
Unit
Factory
Default
Change
Limit
Fb.1.10 Expand multifunctional input terminal EDO1 0~62 1 0
Fb.1.11 Expand multifunctional input terminal EDO2 0~62 1 0
Fb.1.12 Expand multifunctional input terminal EDO3 0~62 1 0
Fb.1.13 Expand multifunctional input terminal EDO4 0~62 1 0
Fb.1.14 Expand multifunctional input terminal ERO1 0~62 1 0
Fb.1.15 Expand multifunctional input terminal ERO2 0~62 1 0
Fb.1.16 Expand multifunctional input terminal ERO3 0~62 1 0
Fb.1.17 Expand multifunctional input terminal ERO4 0~62 1 0
6.2.45 SERVOCONTROL AND SCALE POSITIONING
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
Fb.2.18 Automatic shift frequency 0~5.00Hz 0.01 1.00
Fb.2.19 Automatic shift switching cycle 0.10~2.00Sec. 0.01 0.30
Fb.2.20
Zero frequency torque holdup
(DC bind-type brake preferred)
0: Void
1: Bind-type brake torque effective
2: Position locking(PG feedback
VC mode)
3: Lock in the designated shutdown
angle
1 0 ×
Fb.2.21
Position lock gain1(location
gain)
00.10~10.00 0.01 1.00
Fb.2.22
PG speed shaft propulsion
distance per revolution
0.001~50.000mm 0.01 0.500
Fb.2.23 Servo control function
_ _ _ X: Function selection
0: Void
1: Effective
1 0000 ×
