6.2.27 MOTOR TEMPERATURE DETECTION
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F5.4.43 Motor temperature sensor
0: None
1: 1 X PT100
2: 2 X PT100
3: 3 X PT100
4: PTC sensor
5: Thermoswitch (normally closed)
6: Thermoswitch (normally open)
1 0
F5.4.44
Sensor current source
providing terminal (exceeding
parameter)
0: None
1: AO1
2: AO2
F5.4.45 Temperature input channel
0: None
1: AI1 input (PT100 or PTC)
2: AI3 input (PT100 or PTC)
3: DI1~DI9 (thermoswitch)
1 0
F5.4.46 Alarm action threshold value -10.0~500.0 (0~5000 Ω/PTC) 0.1 110.0
F5.4.47
Protection action threshold
value
-10.0~500.0 (0~5000 Ω/PTC) 0.1 130.0
6.2.28 MULTI-STAGE FREQUENCY SETTING
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F6.0.00 1st operating frequency [F0.1.22]~[F0.1.21] 0.01 5.00
F6.0.01 2nd operating frequency [F0.1.22]~[F0.1.21] 0.01 10.00
F6.0.02 3rd operating frequency [F0.1.22]~[F0.1.21] 0.01 15.00
F6.0.03 4th operating frequency [F0.1.22]~[F0.1.21] 0.01 20.00
F6.0.04 5th operating frequency [F0.1.22]~[F0.1.21] 0.01 25.00
F6.0.05 6th operating frequency [F0.1.22]~[F0.1.21] 0.01 30.00
F6.0.06 7th operating frequency [F0.1.22]~[F0.1.21] 0.01 35.00
F6.0.07 8th operating frequency [F0.1.22]~[F0.1.21] 0.01 40.00
F6.0.08 9th operating frequency [F0.1.22]~[F0.1.21] 0.01 45.00
F6.0.09 10th operating frequency [F0.1.22]~[F0.1.21] 0.01 50.00
F6.0.10 11th operating frequency [F0.1.22]~[F0.1.21] 0.01 25.00
F6.0.11 12th operating frequency [F0.1.22]~[F0.1.21] 0.01 5.00
F6.0.12 13th operating frequency [F0.1.22]~[F0.1.21] 0.01 15.00
F6.0.13 14th operating frequency [F0.1.22]~[F0.1.21] 0.01 35.00
F6.0.14 15th operating frequency [F0.1.22]~[F0.1.21] 0.01 50.00
