V560 Series High Performance Closed-Loop Vector Inverter User Manual
54
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Chang
e Limit
F2.1.32 Stator resistance 0.01~65000mΩ ☆ ☆ ×
F2.1.33 Stator inductance 0.001~6500.0mH ☆ ☆ ×
F2.1.34
Total leakage
inductance
0.001~6500.0mH ☆ ☆ ×
F2.1.35 Rotator time constant 5.0~6500.0ms 0.1ms ☆ ×
F2.1.36
Slip compensation
coefficient
0.25~2.00 0.01 1.00
F2.1.37
~F2.1.49
Retention parameter ×
F2.1.50 Z pulse initial angle 0.0~359.9 0.1 0.0 ×
F2.1.51
Motor overload
protection coefficient
50.0~131.0(%) (131—closed) 0.1 110.0
6.2.13 PARAMETER MEASUREMENT AND PRE-EXCITATION
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F2.2.52
Start excitation time in
vector mode
0.02~2.50Sec. 0.01 ☆
F2.2.53
Motor parameter
measurement
0: Closed
1: Static identification
2: Static + operating parameter
identification
3: Static + operating parameter
identification + revolution ratio
identification
1 0 ×
6.2.14 MULTIFUNCTIONAL INPUT TERMINAL
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F3.0.00
Multifunctional input
terminal DI1
0~96 1 0 ×
F3.0.01
Multifunctional input
terminal DI2
0~96 1 0 ×
F3.0.02
Multifunctional input
terminal DI3
0~96 1 7 ×
F3.0.03
Multifunctional input
terminal DI4
0~96 1 8 ×
F3.0.04
Multifunctional input
terminal DI5
0~96 1 13 ×
F3.0.05
Multifunctional input
terminal DI6
0~96 1 0 ×
¾ The stator resistance, stator inductance and the Minimum Unit of total leakage inductance
of as
y
nchronous motors is relevant with different models.
