Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
66
6.2.29 SIMPLE PROGRAMMABLE MULTI-STAGE OPERATION
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F6.1.15
Selection of
programmable
multi-stage speed
operation mode (H)
_ _ _ X: Function selection
0: Function closed
1: Multi-stage frequency/revolution
operation effective
2: Multi-stage frequency/revolution
operation condition effective (Function
No. 23)
3: Multi-stage PID setting operation
effective
4: Multi-stage PID setting operation
condition effective (Function No. 23)
_ _ X _: Operation mode
0: Single cycle
1: Single cycle stop mode
2: Continuous cycle
3: Continuous cycle stop mode
4: Keeping the final value
5: Keeping the final value stop mode
_ X _ _: Selection of breakpoint/stop
recovery mode
0: Restore running at the first stage
1: Start running at the interruption time
(effective for multi-stage frequency/
revolution operation)
2: Start running at the stage of interruption
X _ _ _: Power-off status storage
0: Not stored 1: Stored
1 0000 ×
F6.1.16 Stage 1 setting (H)
_ _ _ X: Hz of each stage
0: Multi-stage frequency setting 1~15/
Process PID multi-stage setting 1~7
1: Frequency command (F0.1.16)/
Process PID setting (F7.0.01)
_ _ X _: Direction setting
0: FWD
1: REV
2: Determined by the running command
channel
_ X _ _: Accele/decele of each stage
0: Acceleration and deceleration time 1
1: Acceleration and deceleration time 2
2: Acceleration and deceleration time 3
3: Acceleration and deceleration time 4
X _ _ _: Each stage time unit
0: Sec. 1: Min.
1 0000
F6.1.17 Stage 2 setting (H) 1 0000
F6.1.18 Stage 3 setting (H) 1 0000
F6.1.19 Stage 4 setting (H) 1 0000
F6.1.20 Stage 5 setting (H) 1 0000
F6.1.21 Stage 6 setting (H) 1 0000
F6.1.22 Stage 7 setting (H) 1 0000
F6.1.23 Stage 8 setting (H) 1 0000
F6.1.24 Stage 9 setting (H) 1 0000
F6.1.25 Stage 10 setting (H) 1 0000
F6.1.26 Stage 11 setting (H) 1 0000
F6.1.27 Stage 12 setting (H) 1 0000
F6.1.28 Stage 13 setting (H) 1 0000
F6.1.29 Stage 14 setting (H) 1 0000
F6.1.30 Stage 15 setting (H) 1 0000
F6.1.31 Stage 1 running time 0.0~6500.0(Sec./Min.) 0.1 0.0
F6.1.32 Stage 2 running time 0.0~6500.0(Sec./Min.) 0.1 0.0
F6.1.33 Stage 3 running time 0.0~6500.0(Sec./Min.) 0.1 0.0
F6.1.34 Stage 4 running time 0.0~6500.0(Sec./Min.) 0.1 0.0
