Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
59
6.2.21 ANALOG INPUT POWER FAILURE DETECTION
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Chang
e Limit
F4.3.36
Analog input power
failure detection function
_ _ _ X: AI1power failure detection
0: Void 1: Effective
_ _ X _: AI2 power failure detection
0: Void 1: Effective
_ X _ _: AI3 power failure detection
0: Void 1: Effective
1 0000 ×
F4.3.37
AI1 power failure
detection threshold
0.00~10.00V 0.01 0.25
F4.3.38
AI1 power failure
detection delay time
0.01~50.00Sec. 0.01 2.00
F4.3.39
AI1 power failure
detection response
0: No action (for non-stop alarm)
1: Forcedly set to the minimum
2: Forcedly set to the maximum
3: Forcedly set to the defaults value
(F4.3.40)
4: Inverter forced trip stop
1 0 ×
F4.3.40
AI1 power failure default
value
0.00~10.00V 0.01 0.0
F4.3.41
AI2 power failure
detection threshold
0.00~20.00mA 0.01 4.00
F4.3.42
AI2 power failure
detection delay time
0.01~50.00Sec. 0.01 2.00
F4.3.43
Action selection after AI2
power failure
0: No action(for non-stop alarm)
1: Forcedly set to the minimum
2: Forcedly set to the maximum
3: Forcedly set to the defaults value
(F4.3.44)
4: Inverter forced trip stop
1 0 ×
F4.3.44
AI2 power failure default
value
0.00~20.00mA 0.01 4.00
F4.3.45
AI3 power failure
detection upper threshold
-10.00~10.00V 0.01 0.25
F4.3.46
AI3 power failure
detection lower threshold
-10.00~10.00V 0.01 -0.25
F4.3.47
AI3 power failure
detection delay time
0.01~50.00Sec. 0.01 2.00
F4.3.48
AI3 power failure
detection response
0: No action(for non-stop alarm)
1: Forcedly set to the minimum
2: Forcedly set to the maximum
3: Forcedly set to the defaults value
(F4.3.49)
4: Inverter forced trip stop
1 0 ×
F4.3.49
AI3 power failure default
value
-10.00~10.00V 0.01 0.0
