Sunfar V560 Series User Manual

Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
89
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
0: Electric operation
1: Power generation operation
X _ _ _: Limit suppression
0: No action
1: Over current suppression action
2: Overvoltage suppressor action
3: under voltage suppression action
dE.0.18
Accumulative startup
running time at the last fault
0~65535 1h 65535 R/I
dE.0.19
Startup running interval
between the last two faults
0~65535 1h 65535 R/I
dE.0.20 Actual output frequency -300.00~300.00Hz 0.01 0 R/I
6.2.53 BASIC STATUS PARAMETER
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
d0.0.00
Output frequency and direction
(rotor synchronous frequency)
-300.0Hz ~ 300.00Hz 0.01Hz R
d0.0.01 Motor revolution and direction -30000~30000rpm 1rpm R
d0.0.02 Output current 0.0~ 6000.0A 0.1A R
d0.0.03 Output torque -300.0~300.0% 0.1% R
d0.0.04 Output voltage 0~500V 1V R
d0.0.05 Output power -1000.0~1000.0KW 0.1KW R
d0.0.06
Device body maximum
temperature
0~150.0°C 0.1°C R
d0.0.07 Voltage at DC side 0~1000V 1V R
d0.0.08 Inverter running status
_ _ _ X: Operation mode
0: V/F mode
1: Open-loop vector speed
2: Closed-loop vector speed
3: Open-loop torque control
4: Closed-loop torque control
5: V/F separated control
_ _ X _: Operation status
0: Stop
1: Start acceleration
2: Stop deceleration
3: Decreasing frequency and
deceleration
4: Steady operation
_ X _ _: Electric/ braking
status
0: Electric operation
1: Power generation operation
X _ _ _: Limit suppression
0: No action
1: Over current suppression
action
1 R
