V560 Series High Performance Closed-Loop Vector Inverter User Manual
88
6.2.51 HISTORICAL FAULT RECORDING
Function
Code
Name Setting Range and Description
Minimu
m Unit
Factory
Default
Change
Limit
dE.0.00 Last time fault recording - - - R/I
dE.0.01 Historical fault 1 - - - R/I
dE.0.02 Historical fault 2 - - - R/I
dE.0.03 Historical fault 3 - - - R/I
dE.0.04 Historical fault 4 - - - R/I
dE.0.05 Historical fault 5 - - - R/I
dE.0.06 Historical fault 6 - - - R/I
dE.0.07 Historical fault 7 - - - R/I
6.2.52 OPERATION STATUS AT THE LAST FAULT
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
dE.0.08
Operating frequency (rotor
synchronous frequency)
-300.00~300.00Hz 0.01 0 R/I
dE.0.09 Output current 0.0~3000.0A 0.1 0 R/I
dE.0.10 Output voltage 0~1000V 1 0 R/I
dE.0.11 Detection motor revolution 0~30000rpm 1 0 R/I
dE.0.12 Voltage at the DC side 0~1000V 1 0 R/I
dE.0.13 Output torque -300.0~ 300.0% 0.1% 0 R/I
dE.0.14 Target frequency 0.0~300.00Hz 0.01 0 R/I
dE.0.15
Equipment maximum
temperature
0.0~150.0 0.1°C 0 R/I
dE.0.16 Command status
_ _ _ X:
0: Stop command
1: Running command
_ _ X _: Reserved
_ X _ _: Reserved
X _ _ _: Reserved
1 0000 R/I
dE.0.17 Inverter operation status
_ _ _ X: Operation mode
0: V/F mode
1: Open-loop vector speed
2: Closed-loop vector speed
3: Open-loop torque control
4: Closed-loop torque control
_ _ X _: Operation status
0: Stop
1: Start acceleration
2: Stop deceleration
3: Decreasing frequency and
deceleration
4: Steady operation
_ X _ _: Electric/braking status
1 0000 R/I
