2 Product Confirmation And Operation Cautions
V560 Series High Performance Closed-Loop Vector Inverter User Manual
1.2.1 NOTICES DURING INSTALLATION
1. The frequency inverter shall not be installed on combustibles, in case of the risk of fire.
2. The frequency inverter shall not be installed at places with direct sunlight, in case of danger.
3. The frequency inverter of this series shall not be installed in the environment of explosive gases, in case of
the danger of explosion.
4. Do not install the Frequency inverter if damaged or lf components are missing. Installation may lead to
personal injury, fire or other accidents.
5. Do not remove or modify the frequency inverter without authorization.
6. No foreign matter is allowed to be dropped into the frequency inverter, in case of breakdown of the
frequency inverter.
7. During installation, the frequency inverter shall be installed at the place able to bear its weight; otherwise, it
may fall down.
1.2.2 SAFETY CAUTION FOR WIRING
1. Please authorize the professional staff to conduct wiring. If the wiring operation is not proper, it may
damage to the equipment and the individuals.
2. Please start to wire after the panel digital tube of frequency inverter is out for ten minutes, otherwise, there
can be electric shock risk.
3. The grounding terminal of frequency inverter must be reliably grounded; otherwise, there can be electric
shock risk.
4. Connection of AC power onto the output terminals U, V and W of frequency inverter, will damage the
frequency inverter, and may lead to personal injury.
5. Confirm that the input voltage and frequency converter are in consistent with rated voltage value;
otherwise, the frequency inverter may be damaged.
6. Confirm that the motor and frequency converter are adaptive with each other, otherwise, the motor can be
damaged or frequency converter protection can be caused.
7. Brake resistor cannot be connected onto the (+), (-) of DC bus directly; otherwise, there can be fire risk.
1.2.3 SAFETY CAUTION FOR RUNNING OPERATION
1. Please do not operate the switch with wet hand; otherwise, there can be electric shock.
2. Please install the front cover prior to plugging in, and shall not demount the cover while power is on,
otherwise, here can be electric shock.
3. During the frequency converter is with power on, even the motor is stopped, do not touch the terminals of
frequency converter, otherwise, here can be electric shock.
4. If you apply the function of restart, do not approach the load equipment, for it may restart suddenly after
alarm removed, otherwise, personal injuries may caused. Please set the system as ensuring personal and
property safety even when restarting.
5. Please set additional emergency stop switch, otherwise, personal injuries may be caused.
6. The temperature of cooling fin and direct current reactor can be very high, therefore, do not touch them, in
case of the danger of burns.
