Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
43
6. FUNCTIONAL PARAMETER TABLE
6.1 EXPLANATIONS
1) The symbols in the Table are explained as below:
♦ "×" indicates that the set value of the parameter cannot be changed when the inverter is running.
♦ " " indicates the parameter is relevant with the model of ☆ the inverter.
♦ "R" indicates the parameter is just for reading and cannot be changed;
♦ "R/I" indicates the parameter is just for reading and cannot be changed, but can be cleared by
initialization.
♦ "—" indicates the parameter is relevant with the type or status of connected accessories.
2) Variables: (H) - hexadecimal number; only bitwise data change is permitted (carry bit is not allowed), and
the upper and lower limit for bitwise change.
6.2 FUNCTION TABLE
6.2.1 SYSTEM MANAGEMENT PARAMETER
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F0.0.00 Macro parameter
_ _ _ X: Application macro (0~F)
0: Void (customized setting)
1: Setting of panel operation digit (factory default)
2: Setting of panel operation shuttle
3: 2 wire control 1(AT1 setting)
4: 2 wire control 2(AT1 setting)
5: 3 wire control 1(AT1 setting)
6: Tool device spindle drive (AT1 setting)
_ _ X _: Reserved
_ X _ _: Configuration macro (reserved)
X _ _ _: System macro (0~F)
0: Standard operation
1: Variable torque load (e.g. load of fans and
pumps)
2: Reserved
1 0000 ×
F0.0.01
Parameter display
and modification (H)
_ _ _ X: Parameter display mode
0: Display all parameters
1: Display effective configuration parameters
2: Display parameters different from factory
default
3: Display modified and stored parameters after
power-on this time
4: Display modified and un-stored parameters
after power-on this time
_ _ X _: Parameter modification mode
0: Effective and permanently stored after
modification
1: Effective after modification but not stored, and
getting lost after power-off
1 0001
