Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
44
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
_ X _ _: Reserved
X _ _ _: Parameter batch recovery and batch
storage
2: Abandon modifying all un-saved parameters
(restoring to original value)
5: Batch storing all modified and un-saved
parameters
9: Resume all parameters to initial values at the
last power-on
F0.0.02
Modification key for
system macro and
configuration macro
parameters
0~65535(1580) 1 0 ×
F0.0.03 Reserve
F0.0.04
LCD display
setting(H)
_ _ _ X: Contrast 0~7
_ _ X _: Normal display mode
0: Steady mode
1: Single parameter display
2: Dual parameter display
3: Three parameter display
1 0023 -
F0.0.05
Parameter
locking(H)
_ _ _ X: Parameter modification permission
0: All parameters are permitted to be modified
1: Except for this parameter, frequency digital
setting, PID digital setting, revolution digital
setting, torque digital setting, locking password
parameter (F0.0.06), other parameters are
forbidden to be modified.
2: All parameters are forbidden to be modified
except for this parameter and the locking
password.
_ _ X _: Coded lock
0: Void
1: Effective – once the password is set, this
parameter cannot be modified unless correct
password is entered.
1 0000
F0.0.06
Parameter locking
password
0~65535 1 0
F0.0.07
Parameter
initialization
0: No action
1: Factory Reset parameter groups F0>F9
2: Factory Reset parameter groups F0>FA
3: Factory Reset parameter groups F0>FB
4: Factory Reset parameter groups F0>FC
5: Factory Reset parameter groups F0>FD
6: Factory Reset parameter groups F0>FE
7: Factory Reset parameter groups F0>FF
8: Clear away fault records
1 0 ×
F0.0.08
Parameter
copying(H)
_ _ _ X: Upload and download
0: No action
1: Parameter upload
2: Parameter download
3: Parameter download
(except for motor parameter/F2 Group)
1 0000 ×
