Sunfar V560 Series User Manual

Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
45
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
_ _ X _: Local download permitted
0: Parameter download forbidden
1: Parameter download permitted
F0.0.09
Motor type and
control mode
selection (H)
LED _ _ _ X: Motor 1 type selection
0: Induction asynchronous motor
1: Spindle asynchronous servo motor
LED _ _ X _: Motor 1 control mode
0: SVC mode/open-loop vector control
1: VC mode/closed-loop vector control
2: V/F control
3: V/F separate control
LED _ X _ _: Motor 2 selection type
0: Induction asynchronous motor
1: Spindle asynchronous servo motor
LED X _ _ _: Motor 2 control mode
0: SVC mode/open-loop vector control
1: VC mode/closed-loop vector control
2: V/F control
3: V/F separate control
1 0000 ×
F0.0.10 Motor selection
0: Motor 1
1: Motor 2
2: Selection of multifunctional input terminal
(Function No.41)
1 0 ×
F0.0.11
Selection of panel
key functions (H)
_ _ _ X: Keypad locking
0: No locking
1: All keys are locked except for UP/DW (Shuttle),
Stop and RUN.
2: All keys are locked except for STOP and RUN
3: All keys are locked except for STOP
4: Lock all keys
_ _ X _: STOP button function
0: Non-panel control mode void
1: Press STOP key in any control mode to stop
the device slowly
2: Press STOP key in any control mode to stop
the device freely
_ X _ _: PANEL/REMOTE button function
0: Void
1: Stop effective
2: Continuously effective
X _ _ _: Reserved
1 0000 ×
F0.0.12
Principal monitoring
parameter (H)
d0.0~d0.55 / d1.0~d1.55 1 d0.00
F0.0.13
Auxiliary monitoring
parameter 1 (H)
d0.0~d0.55 / d1.0~d1.55 1 d0.02
F0.0.14
Auxiliary monitoring
parameter 2 (H)
d0.0~d0.55 / d1.0~d1.55 1 d0.04
