Description Of Specific Functions
V560 Series High Performance Closed-Loop Vector Inverter User Manual
178
2: Alarm deceleration stop
Inverter slows down to stop according to effective time of deceleration, and reports overlarge deviation of
rotating speed (Fu.018) or over-speed fault (Fu.019).
3: Alarm continuing running
Inverter keeps on running, whereas reports overlarge deviation of rotating speed (aL.018) or over-speed
warning (aL.019) at the same time.
F8.2.34 Detected value of excessive
revolution deviation (DEV)
Setting range:
0.0~50.0%
Factory default: 20.0%
F8.2.35 Detection time of excessive
revolution deviation (DEV)
Setting range:
0.0~10.00Sec.
Factory default: 10.00
These parameters are used to set detecting value and time for overlarge deviation of rotating speed (DEV).
Provided that deviation of rotating speed is continuously greater than given DEV detecting value within given
DEV detecting time [F8.2.35], then inverter shall be in line with the setting action of F8.2.32. Set value of
F8.2.34 is corresponding to the percentage of upper limit frequency [F0.1.21].
F8.2.36 Detected value of over
speed (OS)
Setting range: 0.0~150.0% Factory default: 120.0%
F8.2.37 Detection time of over
speed (OS)
Setting range: 0.0~2.00Sec. Factory default: 0.10
These parameters are used to set detecting value and time of over-speed (OS).
Provided that feedback rotating speed is continuously faster than given OS detecting value within given OS
detecting time [F8.2.37], then inverter shall be in line with the
setting action of F8.2.33. Set value of F8.2.36
is corresponding to the percentage of upper limit frequency [F0.1.21].
7.35 TORQUE CONTROL (GROUP F8.3)
F8.3.40 Selection of torque command
channel
Setting range: 0~12 Factory default: 0
0: Digital setting (F8.3.41)
Take the set value of F8.3.41 as given value of torque, and conduct power failure storage.
1: Panel shuttle potentiometer setting
Set value of torque is given by rotational shuttle potentiometer.
2: Analog input AI1
AI1 input voltage value of 0~10V is corresponding to 0~250% of rated torque.
3: Analog input AI2
AI2 input current value of 4~20mA is corresponding to 0~250% of rated torque.
4: Analog input AI3
AI3 input voltage value of -10~10V are corresponding to 0~250% of rated torque.
5: Analog input AI3 (bipolarity)
AI3 input voltage value of -10~10V is corresponding to -250%~250% of rated torque; positive and negative
input of AI3 are corresponding to positive and negative instruction value of torque.
