Description Of Specific Functions
V560 Series High Performance Closed-Loop Vector Inverter User Manual
179
6: Frequency signal input (Fin)
Maximum value of input frequency of Fin terminal is corresponding to 250% of rated torque.
7: Process PID output
For process PID output that given as torque instruction, F7.0.00 parameter needs to be set as #1## for
matching.
8: Compensation PID output
For compensation PID output that given as torque instruction, F9.0.00 parameter needs to be set as #1## for
matching.
9: MODBUS Fieldbus set value 1 (relative set value)
Current torque instruction of inverter is set by principal computer through built-in standard RS485
communication interface of inverter.
10: MODBUS Fieldbus set value 2 (absolute set value)
11: Virtual analog input SAI1
12: Virtual analog input SAI2
F8.3.41 Torque digital setting Setting range: -250~250% Factory default: 0.0
Its set value, the setting with symbols (Direction), is corresponding to the percentage of rated torque; Actual
given direction of torque is “Exclusive OR” of control command direction and set value direction.
