Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
46
6.2.2 SELECTION OF RUNNING COMMANDS
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F0.1.15
Selection of running
command source
0: Control command 1 effective
1: Control command 2 effective
2: Selection of multifunctional input terminal
(Function No. 11)
1 0
F0.1.16
Selection of frequency
set value (when one
source of combination
set is bipolar set, the
final direction of the
combination results
shall be the direction
of setting source1
0: Frequency setting source 1 is independently
effective
1: Frequency setting source 2 is independently
effective
2: Selection of multifunctional input terminal
(Function No.12)
3: Bound with the start-stop command channel
4: Channel 1 + Channel 2
5: Channel 1 amplified by Channel 2
6: Channel 1 - Channel 2
7: Channel 1 reduced by Channel 2
8: Channel 1 reduced by Channel 2
9: Highest value Channel 1 OR Channel 2
10: Lowest value Channel 1 OR Channel 2
11: √(Channel 1) + √(Channel 2)
12: √(Channel 1 + Channel 2)
13: (Channel1 x Scaling1) + (Channel 2 x
Scaling 2)
14: (Channel1 x Scaling1) + (Channel 2 x
Scaling 2)
1 0
F0.1.17 Running direction(H)
_ _ _ X: Direction switch
0: Void
1: Negate
_ _ X _: Direction locking
0: Void (determined by the direction command)
1: FWD locking
2: REV locking
1 0000
F0.1.18
Action coefficient of
frequency setting
channel1
0.01~100.00 0.01 1.00
F0.1.19
Action coefficient of
frequency setting
channel2
0.01~100.00 0.01 1.00
F0.1.20
Maximum output
frequency
10.00~320.00Hz/100.0~2000.0Hz 0.01 60.00
F0.1.21
Upper limiting
frequency
[F0.1.22]~Min. (300.00Hz,[F0.1.20]) 0.01 50.00
F0.1.22
Lower limiting
frequency
0.0Hz~[F0.1.21] 0.01 0.0
F0.1.23 FWD jog frequency 0.0Hz~[F0.1.21] 0.01 10.00
F0.1.24 REV jog frequency 0.0Hz~[F0.1.21] 0.01 10.00
