226 EMC
V560 Series High Performance Closed-Loop Vector Inverter User manual
Chapter 12 EMC
12.1 CE
The product can be sold freely in the market of EEA (European Economic Area) with CE
label, and to be ensured to meet other requirements as LVD and EMC.
12.2 DEFINITION
EMC (Electromagnetic Compatibility) means the capacity of anti-interference for
electric and electron equipments, and the product could not interfere other local equips
also. EMC rules are defined requirements of anti-interference for EU area.
1) 1
st
Environment: including power supply equips of civil low voltage grid.
2) 2
nd
Environment: including power supply equips of non-civil low voltage grid.
z C1 Inverter: when rated power of electric transmission system is under 1000V, use
in 1
st
environment.
z C2 Inverter: when rated voltage of electric transmission system is under 1000V, it
would be plug equips or mobile equips. When it uses in 1
st
environment, it
should install and adjust by professional engineer.
z C3 Inverter: when rated voltage of electric transmission system is under 1000V, it is
suitable in 2
nd
environment, but not 1
st
environment.
z C4 Inverter: when rated voltage of electric transmission system is not under 1000V
or rated current is not lower than 400A, or it is suitable in complicated system
of 2
nd
environment.
12.3 OBEY STANDARD ORDER
12.3.1 OBEY EMC ORDER
V560 Series meet the requirements of standard EN61800-3: 2004 C2, which is
suitable in 1
st
and 2
nd
environment.
12.3.2 OBEY LVD ORDER
V560 Series meet the requirements of standard EN 61800-2.
Installation of 1
st
environment:
1) Inverter chooses suited EMC filter.
2) Select suitable motor and wires.
3) Wiring according to 《Cable Wiring Requirements》.
4) Max output cable length is 100m.
