Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
73
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F8.1.19
PID parameter switching lower
limiting revolution (ASR1 group
parameter low revolution
effective)
0~[F8.1.20] 1 100
F8.1.20
PID parameter switching upper
limiting revolution (ASR2 group
parameter high revolution
effective)
[F8.1.19]~60*[F0.1.21]/
pairs of motor poles (rpm)
1 300
F8.1.21 Proportional gain 1 (ASR-P1) 0.10~2.00 0.01 1.00
F8.1.22 Integration time 1 (ASR-I1) 0.0, 0.01~50.00 Sec. 0.01 1.00
F8.1.23
Differential coefficient 1
(ASR-D1)
0.0, 0.01~10.00 0.01 0.0
F8.1.24
Differential output filtering
constant 1 (ASR-DT1)
0.10~5.00 Sec. 0.01 1.00
F8.1.25 Proportional gain 2 (ASR-P2) 0.10~2.00 0.01 0.80
F8.1.26 Integration time 2 (ASR-I2) 0.0, 0.01~50.00 Sec. 0.01 2.50
F8.1.27
Differential coefficient 2
(ASR-D2)
0.0, 0.01~10.00 0.01 0.0
F8.1.28
Differential output filtering
constant 2 (ASR-DT2)
0.10~10.00 Sec. 0.01 1.00
F8.1.29
Adjustor output upper limit
amplitude
0.0~250.0% 0.1 190.0%
F8.1.30
Adjuster output lower limit
amplitude
-250.0~0.0% 0.1 -190.0%
F8.1.31
Time span of regulator export
filtering
0，0.1~50.0ms
0.1 0
6.2.36 PROTECTION PARAMETER
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F8.2.32 Excessive rotation(DEV) 0: No action
1: Alarm free stop
2: Alarm deceleration stop
3: Alarm continuing running
1 0 ×
F8.2.33 Over speed (OS) protection 1 1 ×
F8.2.34
Over speed protection limit
(DEV)
0.0~50.0% (as compared to upper
limiting frequency)
0.1 20.0%
F8.2.35
Over speed protection
period (DEV)
0.0~10.00Sec. 0.01 10.00
F8.2.36
Over speed protection
value (OS)
0.0~150.0% (as compared to upper
limiting frequency)
0.1 120.0%
F8.2.37
Over speed protection time
(OS)
0.0~2.00Sec. 0.01 0.10
F8.2.38
SVC rotating speed
estimate gain factor
0.10 ~ 10.00 0.01 1.00
