Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
58
Function
Code
Name
Setting Range and
Description
Minimum
Unit
Factory
Default
Change
Limit
F4.1.14 AI2 curve correction value 1 [F4.0.02]~[F4.0.03] 0.01 4.00
F4.1.15 AI2 curve correction point 2 [F4.0.02]~[F4.0.03] 0.01 20.00
F4.1.16 AI2 curve correction value 2 [F4.0.02]~[F4.0.03] 0.01 20.00
F4.1.17
AI3 zero hysteresis/
standard expansion card
0.0~2.00 0.01 0.10
F4.1.18
AI3 curve correction point 1/
standard expansion card
[F4.0.04]~[F4.0.05] 0.01 0.0
F4.1.19
AI3 curve correction value 1/
standard expansion card
[F4.0.04]~[F4.0.05] 0.01 0.0
F4.1.20
AI3 curve correction point 2/
standard expansion card
[F4.0.04]~[F4.0.05] 0.01 10.00
F4.1.21
AI3 curve correction value 2/
standard expansion card
[F4.0.04]~[F4.0.05] 0.01 10.00
6.2.20 ANALOG OUTPUT
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F4.2.22
AO1 mapping variable
(subjecting to F5.4.44
exceeding function )
0~44(monitor variable comparison
table)
1 0
F4.2.23
AO2 mapping
variable/standard
expansion card
0~44 (monitor variable comparison
table)
1 2
F4.2.24 AO1 mini value 0.00~10.00V 0.01 0.0
F4.2.25 AO1 max value 0.00~10.00V 0.01 10.00
F4.2.26 AO1 lower limiting value 0.0~[F4.2.27] 0.1 0.0
F4.2.27 AO1 upper limiting value [F4.2.26]~100.0 (%) 0.1 100.0
F4.2.28
AO1 filtering time
coefficient
0.01~10.00Sec. 0.01 0.10
F4.2.29
AO1 fixed output value
(at the time of fixed
output value)
0.0~20.00mA (0.0~10.00V) 0.01 0.0
F4.2.30 AO2 min value 0.00~10.00V 0.01 0.0
F4.2.31 AO2 max value 0.00~10.00V 0.01 10.00
F4.2.32 AO2 lower limiting value 0.0~[F4.2.33] 0.1 0.0
F4.2.33 AO2 upper limiting value [F4.2.32]~100.0 (%) 0.1 100.0
F4.2.34
AO2 filtering time
coefficient
0.01~10.00Sec. 0.01 0.10
F4.2.35
AO2 fixed output value
(at the time of fixed
output value)
0.0~20.00mA (0.0~10.00V) 0.01 0.0
