Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
53
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F1.4.52 Selection of self resetting fault
_ _ _ X: Over current
0: Self resetting forbidden
1: Self resetting permitted
_ _ _ X: Overvoltage
0: Self resetting forbidden
1: Self resetting permitted
_ _ _ X: Output grounding
0: Self resetting forbidden
1: Self resetting permitted
X _ _ _: Running under voltage
0: Self resetting forbidden
1: Self resetting permitted
1 0000
F1.4.53 Display coefficient 0.001~60.000 0.001 1.000
6.2.11 VECTOR RUNNING PARAMETERS (MOTOR 1)
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Chang
e Limit
F2.0.00
Rated power 0.1~400.0KW 0.1KW ☆ ×
F2.0.01 Rated voltage 30~480V 1V 380/220 ×
F2.0.02
Rated current 0.01~650.00A 0.01A ☆ ×
F2.0.03 Rated frequency max{5.00,[F2.0.04]/60}~300.00Hz 0.01Hz 50.00 ×
F2.0.04
Rated revolution 10~min.{30000,60*[F2.0.03]}rpm 1rpm ☆ ×
F2.0.05 Idling current 0.15*[F2.0.02]~0.8*[F2.0.02] 0.01A ☆ ×
F2.0.06
Stator resistance 0.01~65000mΩ ☆ ☆ ×
F2.0.07
Stator inductance 0.001~6500.0mH ☆ ☆ ×
F2.0.08 Total leakage inductance 0.001~6500.0mH ☆ ☆ ×
F2.0.09
Rotator time constant 5.0~6500.0ms 0.1ms ☆ ×
F2.0.10
Slip compensation
coefficient
0.25~2.00 0.01 1.00
F2.0.11
~F2.0.23
Retention parameter ×
F2.0.24
Z pulse initial angle 0.0~359.9 0.1 0.0 ×
F2.0.25
Motor overload
protection coefficient
50.0~131.0(%) (131—closed) 0.1 110.0
6.2.12 VECTOR RUNNING PARAMETERS (MOTOR 2)
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Chang
e Limit
F2.1.26 Rated power 0.1~1000.0KW 0.1 KW ☆ ×
F2.1.27 Rated voltage 30~480V 1V 380/220 ×
F2.1.28 Rated current 0.01~650.00A 0.01A ☆ ×
F2.1.29 Rated frequency max{5.00,[F2.1.30]/60}~300.00Hz 0.01Hz 50.00 ×
F2.1.30 Rated revolution 10~min.{30000,60* [F2.1.29]}rpm 1rpm ☆ ×
F2.1.31 Idling current 0.15*[F2.1.28]~0.8* [F2.1.28] 0.01A ☆ ×
To Next Page
