Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
91
6.2.54 AUXILIARY STATUS PARAMETER
Function
Code
Name
Setting Range and
Description
Minimum
Unit
Factory
Default
Change
Limit
d0.1.30 Frequency setting source 1 set value 0.0~300.00Hz 0.01Hz - R
d0.1.31 Frequency setting source 2 set value 0.0~300.00Hz 0.01Hz - R
d0.1.32 Frequency/revolution integrator output -300.0Hz~300.00Hz 0.01Hz - R
d0.1.33 Stator synchronous frequency -300.0Hz~300.00Hz 0.01Hz - R
d0.1.34 Actually measured revolution value -30000~30000rpm 1rpm - R
d0.1.35 Inverter overload integrator value 0 ~ 1020 1 -
d0.1.36
Process PID set variable (physical
quantity)
0.01~60000 0.01 - R
d0.1.37
Process PID feedback variable
(physical quantity)
0.01~60000 0.01 - R
d0.1.38
Compensation PID set variable
(physical quantity)
0.01~60000 0.01 - R
d0.1.39
Compensation PID feedback variable
(physical quantity)
0.01~60000 0.01 - R
d0.1.40 Torque current -3000.0~3000.0A 0.1A - R
d0.1.41 Excitation current 0.0~3000.0A 0.1A - R
d0.1.42 Device body temperature detection 1 0~150.0°C 0.1°C - R
d0.1.43 Device body temperature detection 2 0~150.0°C 0.1°C - R
d0.1.44 Device body temperature detection 3 0~150.0°C 0.1°C - R
d0.1.45 Motor temperature 0~250.0°C 0.1°C - R
6.2.55 MODBUS FIELDBUS STATUS PARAMETER (Standard Expansion Card)
Function
Code
Name
Setting Range and
Description
Minimu
m Unit
Factory
Default
Change
Limit
d0.2.46 Bus communication set value 1 -10000~10000 1 R
d0.2.47 Bus communication set value 2 -30000~30000 1 R
d0.2.48 Bus command word 1 (HEX) 0~0FFFFH 1 R
d0.2.49 Bus command word 2 (HEX) 0~0FFFFH 1 R
d0.2.50 Bus status word 1 (HEX) 0~0FFFFH 1 R
d0.2.51 Bus status word 2 (HEX) 0~0FFFFH 1 R
d0.2.52 Total quantity of bus information 0~65535 1 R
d0.2.53 Number of bus CRC check errors 0~65535 1 R
d0.2.54 Number of error data accepted by bus 0~65535 1 R
d0.2.55 Number of effective data of bus 0~65535 1 R
