Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
90
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
2: Overvoltage suppressor
action
3: under voltage suppression
action
d0.0.09
Frequency setting channel
command ( frequency)
-300.00Hz ~ 300.00Hz 0.01Hz R
d0.0.10
Revolution Setting channel
command (Revolution)
-30000~30000rpm 1rpm R
d0.0.11
Torque command value (set
input)
-300.0~300.0% 0.1% R
d0.0.12
Target operating frequency
(integrator input)
-300.0Hz ~ 300.00Hz 0.01Hz R
d0.0.13
Target running revolution
(integrator input)
-30000~30000rpm 1rpm
d0.0.14 Speed adjuster deviation -3200~3200rpm 1rpm
d0.0.15 Speed adjuster output -300.0~300.0(%) 0.1%
d0.0.16 Process PID setting -100.0~100.0(%) 0.1%
d0.0.17 Process PID feedback -100.0~100.0(%) 0.1%
d0.0.18 Process PID deviation -100.0~100.0(%) 0.1%
d0.0.19 Process PID output -100.0~100.0(%) 0.1%
d0.0.20 Compensation PID setting -100.0~100.0(%) 0.1%
d0.0.21 Compensation PID feedback -100.0~100.0(%) 0.1%
d0.0.22 Compensation PID deviation -100.0~100.0(%) 0.1%
d0.0.23 Compensation PID output -100.0~100.0(%) 0.1%
d0.0.24 Accumulative running time (H) 0~65535h 1h
d0.0.25 Accumulative power-on time (H) 0~65535h 1h
d0.0.26
Power-on (hh.mm.s) cycling
timing
00.00.0~23.59.9 1
d0.0.27 Kilowatt-hour counter (low) 0~1000.0KWh 0.1KWh
d0.0.28 Kilowatt-hour counter (high) 0~60000KKWh 1KKWh
d0.0.29 Megawatt hour counter 0~60000MW 1 MW
