Description Of Specific Functions 135
V560 Series High Performance Closed-Loop Vector Inverter User Manual
7.13 MULTIFUNCTIONAL INPUT TERMINAL (GROUP F3.0)
F3.0.00~F3.0.05 Multifunctional input
terminals DI1~DI6
Setting range: 0~96 ——
F3.0.06 Multifunctional input terminal
DI7/ standard expansion card
Setting range: 0~96 Factory default: 0
F3.0.07 Multifunctional input terminal
DI8/ standard expansion card
Setting range: 0~96 Factory default: 0
F3.0.08 Multifunctional input terminal
DI9/Fin/standard expansion card
Setting range: 0~98 Factory default: 97
Control terminals Dl1~Dl9/Fin are functional programmable switch input terminals; They can define the
Dl1~Dl9/Fin functions respectively by way of the setup of F3.0.00~F3.0.08 values; See their set values and
relevant functions as Table 1 (Contrast Table of Multifunctional Terminals (DI/EDI/SDI) Function).
For example: Define F3.0.00 as 23, so the function of DI1 can be defined as "Simple PLC Multi-stage
Operation Input"; When the DI1 terminal status validates, simple PLC multi-stage operation input function
can be realized.
The function specifications in the table as following:
1~4: Multi-speed control terminals 1~4
By means of the ON/OFF status combinations of these four functional terminals, select the set frequencies
relevant to F6.0.00~F6.0.15 parameters as the current set frequencies of frequency converter. The priority of
the frequency instruction is higher than frequency set channel F0.1.16.
Table 7-3 Multi-speed operation selection table
Multi-speed
control 4
Multi-speed
control 3
Multi-speed
control 2
Multi-speed
control 1
Frequency set
OFF OFF OFF OFF
Ordinary operation frequency
(F0.1.16 determined)
OFF OFF OFF ON Multi-stage operation frequency 1
OFF OFF ON OFF Multi-stage operation frequency 2
OFF OFF ON ON Multi-stage operation frequency 3
OFF ON OFF OFF Multi-stage operation frequency 4
OFF ON OFF ON Multi-stage operation frequency 5
OFF ON ON OFF Multi-stage operation frequency 6
OFF ON ON ON Multi-stage operation frequency 7
ON OFF OFF OFF Multi-stage operation frequency 8
ON OFF OFF ON Multi-stage operation frequency 9
ON OFF ON OFF Multi-stage operation frequency 10
ON OFF ON ON Multi-stage operation frequency 11
ON ON OFF OFF Multi-stage operation frequency 12
ON ON OFF ON Multi-stage operation frequency 13
ON ON ON OFF Multi-stage operation frequency 14
ON ON ON ON Multi-stage operation frequency 15
