6.2.37 TORQUE CONTROL
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F8.3.39
Torque control
activation
0: Void 1: Effective
2: Multifunctional terminal selection effective
(Function No. 34)
1 0 ×
F8.3.40
Torque control
reference
(selecting the
command
direction)
0: Digital setting (F8.3.41)
1: Panel shuttle potentiometer setting
2: Analog inputAI1
3: Analog inputAI2
4: Analog inputAI3
5: Analog inputAI3 (dual polarity)
6: Frequency signal input (Fin)
7: Process PID output
8: Compensation PID output
9: MODBUS Fieldbus set value 1
10: MODBUS Fieldbus set value 2
11: Virtual analog input SAI1
12: Virtual mode input SAI2
1 0
F8.3.41
Torque digital
setting
-250.0~250.0 (%) 0.1 0.0
F8.3.42
Torque digital rise
time
0.0~50.000Sec. 0.001 0.010
F8.3.43
Torque digital fall
time
0.0~50.000Sec. 0.001 0.010
F8.3.44
Revolution limiting
setting
_ _ _ X: FWD revolution limiting setting
source
0: Setting of FWD revolution limiting value
(F8.3.45)
1: Determination of frequency Setting channel
1 (F0.2.25)
_ _ X _: Reserved
_ X _ _: REV Revolution limiting setting
source
0: Setting of REV revolution limiting value
(F8.3.46)
1: Determination of frequency Setting channel
2 (F0.2.26)
1 0000
F8.3.45
FWD revolution
limiting value
0~60*[F0.1.21]/pairs of motor poles (rpm) 1 1500
F8.3.46
REV revolution
limiting value
0~60*[F0.1.21]/pairs of motor poles (rpm) 1 1500
F8.3.47
Setting of torque
set value limit
_ _ _ X: Minimum torque selection source
(negative torque limit)
0: Minimum torque set value 1 (F8.3.48)
1: Minimum torque set value 2 (F8.3.49)
2: Multifunctional selection terminal setting 1 or
2
3: AI1 set value
4: AI2 set value
5: MODBUS Fieldbus set value 1
1 0000
