Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
77
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F9.0.15
Actual value
multiplication factor
0.01~100.00 0.01 1.00
F9.0.16
Sensor value when
actual value is 100%
0.01~100.00 0.01 1.00
F9.0.17
~
F9.0.20
Reserved
6.2.39 COMPENSATION PID CONTROLLER PARAMETER SELECTION
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F9.1.21
Selection and switching of
controller parameters
_ _ _ X: PID parameters
0: Single PID parameter
1: Dual PID parameters
2: Three PID parameters
3: Four PID parameters
_ _ X _: PID parameter switching mode
0: As per set value
1: As per feedback value
2: As per output frequency
3: Selected by multifunctional terminal
(Function No.63 and 64)
1 0020
F9.1.22
Controller parameter
switching transition
coefficient
0.01 ~ 50.00 0.01 1.00
F9.1.23
Lower limit for group 1/2
parameter switching
0.0~[F9.1.24] 0.1 0.0
F9.1.24
Upper limit for group 1/2
parameter switching
[F9.1.23]~100.0 (%) 0.1 0.0
F9.1.25
Lower limit for group 2/3
parameter switching
[F9.1.24]~[F9.1.26] 0.1 100.0
F9.1.26
Upper limit for group 2/3
parameter switching
[F9.1.25]~100.0 (%) 0.1 100.0
F9.1.27
Lower limit for group 3/4
parameter switching
[F9.1.26]~[F9.1.28] 0.1 100.0
F9.1.28
Upper limit for group 3/4
parameter switching
[F9.1.27]~100.0 (%) 0.1 100.0
F9.1.29 Proportional gain 2 0.0~100.00 0.01 2.00
F9.1.30 Integration time 2 0.0, 0.01~100.00Sec. 0.01 2.00
F9.1.31 Differential coefficient2 0.0, 0.01~10.00 0.01 0.0
F9.1.32
Differential output filtering
constant 2
0.01~25.00Sec. 0.01 5.00
F9.1.33
Adjuster output filtering
time coefficient 2
0.0, 0.01~20.00Sec. 0.01 1.00
F9.1.34 Proportional gain 3 0.0~100.00 0.01 2.00
F9.1.35 Integration time 3 0.0, 0.01~100.00Sec. 0.01 2.00
F9.1.36 Differential coefficient3 0.0, 0.01~10.00 0.01 0.0
