V560 Series High Performance Closed-Loop Vector Inverter User manual
• Insulation resistance: iron core-winding 1000VDC, insulation resistance ≥100MΩ；
• Reactor noise is less than 70dB (test at the point of 1m horizontal distance with
reactor)；
• Temperature rise is less than 70K.
2, Parameter Configuration of AC Input Reactor
Inverter Power
(KW)
Reactor Model
Size
L*W*H (mm)
Mounting
Dimension
(mm)
Installation
Terminal Aperture
(mm)
0.7 AKSG10A/5V 140*85*140 75*55 Φ6
1.1 AKSG10A/5V 140*85*140 75*55 Φ6
1.5 AKSG10A/5V 140*85*140 75*55 Φ6
2.2 AKSG10A/5V 140*85*140 75*55 Φ6
3.0 AKSG10A/5V 140*85*140 75*55 Φ6
4.0 AKSG15A/5V 140*85*140 75*55 Φ6
5.5 AKSG15A/5V 140*85*140 75*55 Φ6
7.5 AKSG20A/5V 175*130*140 82*75 Φ6
9.0 AKSG30A/5V 175*130*140 82*75 Φ6
11 AKSG30A/5V 175*130*140 82*75 Φ6
15 AKSG40A/5V 210*120*190 110*70 Φ8
18.5 AKSG50A/5V 210*120*190 110*70 Φ8
22 AKSG60A/5V 210*165*170 110*85 Φ8
30 AKSG80A/5V 210*165*170 110*85 Φ8
37 AKSG110A/5V 210*165*170 110*85 Φ8
45 AKSG125A/5V 210*165*170 110*85 Φ8
55 AKSG150A/5V 270*170*220 155*85 Φ10
12.4.4 AC OUTPUT REACTOR
AC output reactor is mounted at output terminal of inverter to restrain capacitive
charging current of connecting cable between inverter and motor, voltage built-up rate of
PWM wave of passivated inverter, improve power factor and quality of power grid as well
as stabilize waveform.
