Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
51
6.2.8 V/F PARAMETERS AND OVERLOAD PROTECTION (MOTOR 1)
Function
Code
Name
Setting Range and
Description
Minimum
Unit
Factory
Default
Change
Limit
F1.2.15 Reference frequency of motor 1
5.00~300.00Hz/
50.0~2000.0Hz
0.01 50.00 ×
F1.2.16 Reference voltage of motor1 50~500V 1 380/220
F1.2.17 V/F curve selection for motor 1
0: Customized curve
1: 1.2 times squares curve
2: 1.5 times squares curve
3: Second square curve
1 0 ×
F1.2.18 Torque increasing voltage for motor1 0.0~20.0% 0.1
F1.2.19
Frequency point 1 of motor 1 V/F
curve
0.0~[F0.1.21] 0.01 0.0 ×
F1.2.20
Voltage point 1 of Motor 1
V/F curve
0~500V 0.1 0.0
F1.2.21 Frequency point2 of motor 1 V/F curve 0.0~[F0.1.21] 0.01 0.0 ×
F1.2.22 Voltage point 2 of Motor 1 V/F curve 0~500V 0.1 0.0
F1.2.23 Frequency point3 of motor 1 V/F curve 0.0~[F0.1.21] 0.01 0.0 ×
F1.2.24 Voltage point 3 of Motor 1 V/F curve 0~500V 0.1 0.0
F1.2.25
Slip frequency compensation for
motor 1
0~150(%) 1 0
6.2.9 V/F PARAMETERS AND OVERLOAD PROTECTION (MOTOR 2)
Function
Code
Name
Setting Range and
Description
Minimum
Unit
Factory
Default
Change
Limit
F1.3.27 Reference frequency of motor 2
5.00~300.00Hz/
50.0~2000.0Hz
0.01 50.00 ×
F1.3.28 Reference voltage of motor 2 50~500V 1 380/220
F1.3.29 V/F curve selection for motor 2
0: Customized curve
1: 1.2 times squares curve
2: 1.5 times squares curve
3: Second square curve
1 0 ×
F1.3.30 Torque increasing voltage for motor2 0.0~20.0% 0.1
F1.3.31
Frequency point 1 of motor 2 V/F
curve
0.0~[F0.1.21] 0.01 0.0 ×
F1.3.32 Voltage point 1 of Motor 2 V/F curve 0~500V 0.1 0.0
F1.3.33
Frequency point 2 of motor 2 V/F
curve
0.0~[F0.1.21] 0.01 0.0 ×
F1.3.34 Voltage point 2 of Motor 2 V/F curve 0~500 0.1 0.0
F1.3.35
Frequency point 3 of motor 2 V/F
curve
0.0~[F0.1.21] 0.01 0.0 ×
F1.3.36 Voltage point 3 of Motor 2 V/F curve 0~500V 0.1 0.0
F1.3.37
Slip frequency compensation for
motor 2
0~150(%) 1 0
