Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
86
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
1: Trip out when phase sequence goes wrong
2: The warning of no shutdown when phase
sequence goes wrong
FF.1.24 Reserved —— —— ——
6.2.48 CORRECTION PARAMETER
Function
Code
Name
Setting Range and
Description
Minimu
m Unit
Factory
Default
Change
Limit
FF.2.25 AI1 zero offset adjustment -0.500~0.500V 0.001 0.0
FF.2.26 AI1 gain correction 0.950~1.050 0.001 1.000
FF.2.27 4mA offset adjudgements for AI2 -0.500~0.500mA 0.001 0.0
FF.2.28 AI2 gain correction 0.950~1.050 0.001 1.000
FF.2.29 AI3 zero offset adjustment -0.500~0.500V 0.001 0.0
FF.2.30 AI3 gain correction 0.950~1.050 0.001 1.000
FF.2.31 AO1 zero offset correction -0.500~0.500V 0.001 0.0
FF.2.32 AO1 gain correction 0.950~1.050 0.001 1.000
FF.2.33 AO2 zero offset correction -0.500~0.500V 0.001 0.0
FF.2.34 AO2 gain correction 0.950~1.050 0.001 1.000
FF.2.35 under voltage action level 320~450V 1 400 ×
FF.2.36
Correction coefficient of DC side
voltage detection value
0.950~1.050 0.001 1.000
6.2.49 SPECIAL FUNCTIONAL PARAMETERS
Function
Code
Name Setting Range and Description
Minimu
m Unit
Factory
Default
Change
Limit
FF.3.37
Torque limit configuration
(H)
_ _ _ X: Constant torque area torque
limitation
0: Only limited by torque limiting
parameter (including Revolution PID
output limit)
1: Also limited by acceleration and
deceleration current level and
maximum permitted current
_ _ X _: Reserved
_ X _ _: Constant power area torque
limitation
0: Treated the same as the constant
torque area
1: Simultaneously adjusted as per
constant power algorithm
1 0101
FF.3.38
Current closed-loop
proportional gain
0.10 ~ 10.00 0.01 1.00
FF.3.39
Current closed-loop
integration time constant
0.10 ~ 10.00 (Sec.) 0.01 1.00
FF.3.40
Total leakage inductance
compensation constant
0.10 ~ 10.00 0.01 1.00
