Sunfar V560 Series User Manual

Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
56
Function
Code
Name
Setting Range and
Description
Minimum
Unit
Factory
Default
Change
Limit
F3.1.25 RO2 power-on delay time 0.0~10.00Sec. 0.01 0.0
F3.1.26 RO2 disconnection delay time 0.0~10.00Sec. 0.01 0.0
F3.1.27 Input variable of monitor 1
0~44 (revering to the
monitor variable
comparison table)
1 0
F3.1.28 Input variables of monitor 2
0~44 (referring to the
monitor variable
comparison table)
1 1
F3.1.29 Input variables of monitor 3
0~44 (referring to the
monitor variable
comparison table)
1 2
F3.1.30
Lower limiting value of monitor 1
variables (relative to full scale value
0.0~100.0 (%) 0.1 0.0
F3.1.31
Upper limiting value of monitor 1
variables (relative to full scale value
0.0~100.0 (%) 0.1 100.0
F3.1.32
Lower limiting value of monitor 2
variables (relative to full scale value
0.0~100.0 (%) 0.1 0.0
F3.1.33
Upper limiting value of monitor 2
variables (relative to full scale value
0.0~100.0 (%) 0.1 100.0
F3.1.34
Lower limiting value of monitor 3
variables (relative to full scale value
0.0~100.0 (%) 0.1 0.0
F3.1.35
Upper limiting value of monitor 3
variables (relative to full scale value
0.0~100.0 (%) 0.1 100.0
6.2.16 PULSE INPUT
(Configured with standard expansion I/O board, and this group of parameters are effective
when D19 selects the frequency input function)
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F3.2.36
Minimum pulse input frequency
DI9/Fin
0.0~100.00KHz 0.01 0.0
F3.2.37
Maximum pulse input frequency
DI9/Fin
0.01~100.00KHz 0.01 10.0
F3.2.38 Pulse detection cycle 1ms~20ms 1 10ms
F3.2.39 Number of single-loop pulse 1~4096 1 1024
F3.2.40
Mechanical transmission ratio
(=pulse shaft revolution: motor
shaft revolution)
0.010 ~ 10.000 0.001 1.000
F3.2.41
Driving wheel diameter
(for liner speed calculation)
0.1~2000.0mm 0.1 100.0
F3.2.42
Maximum accumulative length
value
10m~50000m 1m 50000
F3.2.43 Maximum liner speed 0.01~500.00m/Sec. 0.01 10.00
F3.2.44
Current accumulative length
value
0~50000m 1m — R
F3.2.45 Current liner speed 0.0~500.00m/Sec. 0.01 — R
