V560 Series High Performance Closed-Loop Vector Inverter User Manual
1. PRODUCT CONFIRMATION AND OPERATION
CAUTIONS
1.1 PRODUCT CONFIRMATION
Check the outer packing carefully to see if there is any damage after the arrival of the goods; if there is a
label on the outer packing, please confirm the model and specification of it to see if they are in accordance
with your order. If any damage or discrepancy is found, please contact the supplier promptly for solution.
1.1.1 CONFIRMATION OF FREQUENCY INVERTER BODY AND ACCESSORIES
Confirm the frequency inverter body and accessories carefully when unpacking, to see if there is any
damage during the transit, and if the parts and components are damaged or dropped, and if there is the
frequency inverter entity and the following accessories:
z Operation instruction;
z Certification;
z Product list;
z Other ordered accessories
If there is any omission or damage, please contract the supplier promptly for solution.
1.1.2 NAMEPLATE OF FREQUENCY INVERTER
On the frequency inverter, there is a nameplate marked with model, rated parameters, product serial-number
and bar code of frequency inverter. The content of nameplate is shown as below:
1.2 SAFETY CAUTIONS
Read this instruction carefully prior to installation, wiring, operation and maintenance, to ensure proper
operation of this product.
"Tips", "Attention", " Warning " and " Danger " in this operation manual are defined as follow:
Bar code
Certification logos
Product serial-number
Rated output capability and current
Rated input voltage number of phase,
voltage and frequency
Model of frequency inverter
3PH 380V 50/60Hz
XXXXXXXXXX
3.6KVA 5.5A/4.9KVA 7.5A
TYPE:
SOURCE:
SERIAL No.:
OUTPUT:
V560-4T0022G/4T0030P
¾ Warning: Without operation according to the requirements, moderate injuries or minor
injuries of personnel and material loss may be caused.
¾ Danger: Without operation according to the requirements, serious damage to the
equipment or personnel injuries may be caused.
¾ Attention: Matter requires attention during operation.
¾ Tips: Tips for some useful information.
