6.2.47 PROTECTION FUNCTION CONFIGURATION PARAMETER
Function
Code
Name Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
FF.1.19
Protection action
configuration 1 (H)
_ _ _ X: Operation under voltage protection
0: No action 1: Act
_ _ X _: Output grounding protection
0: No action 1: Act
_ X _ _: Input Voltage lack of phase protection
0: No action
1: Trip and stop
2: Nonstop alarm
X _ _ _: Output current phase shortage or
unbalancing protection
0: No action
1: Trip and stop
2: Nonstop alarm
1 1111
FF.1.20
Protection action
configuration 2 (H)
_ _ _ X: Temperature sensor fault
0: No action
1: Trip and stop
2: Nonstop alarm
_ _ X _: Inverter overheat alarm
0: Closed 1: Act
_ X _ _: Input voltage unbalancing protection
(Void for single camera)
0: No action
1: Trip and stop
2: Nonstop alarm
X _ _ _: Motor over temperature protection
0: No action
1: Trip and stop
2: Nonstop alarm
1 1111
FF.1.21
Protection action
configuration 3 (H)
_ _ _ X: Relay action fault protection
0: No action 1: Act
_ _ X _: Internal data memory abnormity
protection
0: No action 1: Act
_ X _ _: Inverter under voltage operation
alarm
0: Closed 1: Act
X _ _ _: Reserved
1 0111
FF.1.22
Protection action
configuration 4 (H)
_ _ _ X: Drive protection action
0: Closed 1: Act
_ _ X _: Reserved
_ X _ _: A. B impulse anti-receive protection
0: Closed 1: Act
1 0001
FF.1.23
Protective action
configuration 5 (H)
_ _ _ X: warning the message shielded
0: Closed 1: Act (no warning)
_ _ X _: Output supply power protection of
phase sequence (reversed)LED
0: Closed
1 0000
