Functional Parameter Table
V560 Series High Performance Closed-Loop Vector Inverter User Manual
84
Function
Code
Name Setting Range and Description
Minimu
m Unit
Factory
Default
Change
Limit
FF.0.09
Definition of virtual input
function (SDI1)
0~96 1 0 ×
FF.0.10
Definition of virtual input
function (SDI2)
0~96 1 0 ×
FF.0.11
Definition of virtual input
function (SDI3)
0~96 1 0 ×
FF.0.12
Definition of virtual input
function (SDI4)
0~96 1 0 ×
FF.0.13
Definition of virtual input
function (SDI5)
0~96 1 0 ×
FF.0.14
Definition of virtual input
function (SDI6)
0~96 1 0 ×
FF.0.15
Definition of virtual input
function (SDI7)
0~96 1 0 ×
FF.0.16
Definition of virtual input
function (SDI8)
0~96 1 0 ×
FF.0.17
Virtual output- input connection
polarity
_ _ _ X: SDO1-SDI1
0: Homopolar connection
1: Antipolar connection
_ _ X _: SDO2-SDI2
0: Homopolar connection
1: Antipolar connection
_ X _ _: SDO3-SDI3
0: Homopolar connection
1: Antipolar connection
X _ _ _: SDO4-SDI4
0: Homopolar connection
1: Antipolar connection
1 0000 ×
FF.0.18
Virtual output- input connection
polarity
_ _ _ X: SDO5-SDI5
0: Homopolar connection
1: Antipolar connection
_ _ X _: SDO6-SDI6
0: Homopolar connection
1: Antipolar connection
_ X _ _: SDO7-SDI7
0: Homopolar connection
1: Antipolar connection
X _ _ _: SDO8-SDI8
0: Homopolar connection
1: Antipolar connection
1 0000 ×
