V560 Series High Performance Closed-Loop Vector Inverter User Manual
Product Introduction 9
Control
Characteristics
Torque response
time
≦5ms ≦25ms
--
Frequency
resolution
Low frequency mode：0.01Hz；
High frequency mode：0.1Hz.
Frequency
precision
Low frequency mode：digital setting--0.01 Hz,
Analog setting - highest frequency ×0.1%
High frequency mode：digital setting--0.1 Hz,
Analog setting - highest frequency ×0.1%
Load capacity
Universal load mode: 110% - long-term; 150% - 60s; 180% -5s
Steady load mode (capacity increase mode): 105% - long-term;
120% - 60 s; 150% - 1 s
Carrier frequency Three-phase vector composition: 1.5 ~ 12.0KHz
Deceleration and
acceleration time
0.01 - 600.00Sec. / 0.01 - 600.0Min.
Magnetic flux brake
Achieve rapid retarding brake of the motor by increasing the motor's
magnetic flux (30-120% allowed)
DC
brake/band-type
rake
DC brake/band-type brake initial frequency: 0.0 - upper limiting
frequency, brake/band-type brake injection current 0.0 ~ 100.0%
Strike frequency 0.0 ~ 50.00Hz
Typical
Function
Multi-segment
running
16-segment frequency/speed running, independent setting of the
running direction, time and acceleration and deceleration of each
segment; 7-segment process PID setting
Built-in PID
Two built-in PID controller (process PID, compensation PID), can be
either used independently by external equipment or be used to
create complicated internal compensation control.
Wakening and
sleeping
Process PID has simple sleeping and wakening functions.
MODBUS
communication
Standard MODBUS communication protocol (optional) allowing for
flexible parameter reading and mapping
Temperature
detection
Able to receive detecting signals of PT100 or PTC thermo-sensitive
elements, hence allows for over-temperature protection for the
motor or external equipment.
Dynamic braking
(Standard configuration for models below V560-4T0220G/4T0300P)
Actuating voltage: 650~760V, braking ratio: 50~100%
General Functions
Power cut restart; Fault self-recovery, motor parameter
dynamic/static self-identification. Start enabling, operation enabling,
start delay, over current suppression, over voltage/under voltage
suppression, V/F custom curve, analog input curve correction, line
brake detection, textile machinery disturbance (frequency swing)
operation.
Function
Features
Virtual IO terminal
8-circuit one-to-one virtual output and input terminals, allowing for
complicated engineering onsite application in an easy way.
Position servo and
division positioning
Allows for easy servo control and precision positioning of spindle
angle.
Communication
linkage
synchronization
Easily allows for synchronized rotation of multiple rotation, and free
selection of linkage balance of multiple machines based on current,
torque and power, and the position synchronized balance function
can ensure zero cumulative error of multi-machine linkage.
