V560 Series High Performance Closed-Loop Vector Inverter User Manual
Function
Features
Load dynamic
balance
Also allows for dynamic balance of multi-machine load (not limited to
communication linkage) and able to achieve torque motor
characteristics.
Strong starting
torque
For load featuring high inertia and high static friction, super strong
starting torque for certain period can be set.
Setting priority
Users can freely select the priority of various frequency/revolution
setting channel; Suitable for combined application for various
occasions.
Setting
combinations
Up to hundreds of setting combinations of frequency, revolution and
torque.
Compensation PID
Especially built-in compensation PID, flexibly allowing for tension
control, drawing machine control and other special applications.
Dual motor
parameter
With two sets of asynchronous motor parameters, allowing for motor
switch even in the mode of vector control.
Timer
3 built-in timers: 5 kinds of time, 5 kinds of trigger modes, multiple
door access signals and working modes, and 7 kinds of output
signals.
Counter
2 built-in counters: Time margin selection, 4 kinds of trigger modes
and 7 kinds of output signal
Macro parameter
Application macro: Allowing for conveniently setting and partially
curing multiple common group parameters and simplifying
parameter setting for common applications.
System macro: Allowing for conveniently switching equipment’s
working mode, and automatically redefining local parameters.
Parameter testing
Any un-stored parameter tested on site can be stored with one key
or abandoned and restored to original value.
Parameter display
Allowing for automatically shielding parameters of unused functional
modules or selectively displaying modified, stored or changed
parameters.
Protection
Function
Power supply
Under voltage protection and three-phase power supply unbalancing
protection
Running protection
Over current protection, over voltage protection, inverter over
temperature protection, inverter overload protection, motor overload
protection, output phase lack protection, and module drive
protection.
Equipment
abnormity
Current detected abnormity, EEPROM memory abnormity, and
abnormal control unit, motor over temperature, MC pull-in fault, and
temperature acquisition loop fault.
Motor connection
Motor not connected, motor’s three-phased parameters unbalanced
and parameter misidentification.
Extension card Detect and protect the extension card for compatibility or conflict.
Environment
Installation
environment
Indoor vertical installation, not subjecting to direct sunshine, free of
dust, corrosive and flammable gas, oil mist, vapor and free of drips
or salt.
Altitude
0~1000 m. The output current capability drops by 10% for every rise
of 1000 m.
Ambient
temperature
Working ambient temperature: -10°C ~ +45°C
Storage ambient temperature: -20°C ~ +60°C
Humidity Blow 95%, no condensed water
Vibration < 20m/s
