220 Description Of Communication Protocol
V560 Series High Performance Closed-Loop Vector Inverter User manual
2) Discrete Input Address Summary (0x1100 ~ 0x1200)
Relevant Modbus functional codes: 0x02 (read input status)
Register name Function Description Access Address
Status Character – Digit 0 Ready 0x1100
Status Character – Digit 1 Operation allowed 0x1101
Status Character – Digit 2 Starting allowed 0x1102
Status Character – Digit 3 Keep 0x1103
Status Character – Digit 4 Operation status 0x1104
Status Character – Digit 5 Direction 0x1105
Status Character – Digit 6 Zero speed 0x1106
Status Character – Digit 7 Acceleration 0x1107
Status Character – Digit 8 Deceleration 0x1108
Status Character – Digit 9 Arrival 0x1109
Status Character – Digit 10 Keep 0x110A
Status Character – Digit 11 Keep 0x110B
Status Character – Digit 12 Instruction source 0x110C
Status Character – Digit 13 Command source 0x110D
Status Character – Digit 14 Warning 0x110E
Status Character – Digit 15 Failure 0x110F
DI1 Multi-purpose input terminal 1 0x1120
DI2 Multi-purpose input terminal 2 0x1121
DI3 Multi-purpose input terminal 3 0x1122
DI4 Multi-purpose input terminal 4 0x1123
DI5 Multi-purpose input terminal 5 0x1124
DI6 Multi-purpose input terminal 6 0x1125
EDI1 Multi-purpose input terminal 7 (extendable card) 0x1130
EDI2 Multi-purpose input terminal 8 (extendable card) 0x1131
EDI3 Multi-purpose input terminal 9 (extendable card) 0x1132
Keep 0x1133~0x1199
