SVAN 958A User Manual
Number of the records from the
logger taken into account after the
fulfilment of the triggering condition
(TriggerPost)
q
qnn - number of the records taken into account
after the fulfilment of the triggering condition
(0 ÷ 200)
Delay in the start of measurement
Y
Ynn nn delay given in milliseconds (0 ÷ 60000)
Reference level for acceleration
(RefLev_a)
Xa
Xannn nnn reference level for acceleration given in
µms
-2
(1 ÷ 100)
Reference level for velocity
(RefLev_v)
Xv
Xvnnn nnn reference level for velocity
given in nms
-1
(1 ÷ 100)
Reference level for displacement
(RefLev_d)
Xd
Xdnnn nnn reference level for displacement given in
pm (1 ÷ 100)
AutoSave option
XA
XA0 - switched OFF
XA1 - switched ON, file names are numbered
Saving results of statistical analysis
XS
XS0 - switched off
XS1 - switched on
Using the RAMfile instead of the
flash disk while storing results with
the AutoSave option switched on
XR
XR0 - switched OFF
XR1 - switched ON
External I/O Mode
x
x0 - AC/Int. in Analogue mode
x1 - AC/Int. in Digital In mode
x2 - AC/Int. in Digital Out mode
External I/O Channel for analogue
AC/Int. mode
y
yn - n - channel number between 1 and 4
State of the instrument
(Stop or Start)
S
S0 - STOP
S1 - START/CONTINUE
S2 - PAUSE
S3 - waiting for trigger (read only)
Menu lock mode
Xb
Xb0 - menu unlocked
Xb1 - menu partially locked
Xb2 - menu fully locked
Channel selection for vibration
vector calculation
XB
XB0:n - channel n is not included in vector
XB1:n - channel n is included in vector
Channel coefficient for vector
calculation
XC
XCxx:n - xx - value of coefficient *100 (0 ÷ 200)
- n - channel number
Storing vector in logger file
XD
XD0 - switched OFF
XD1 - switched ON
Measurement of vibration dose
XE
XE0 - switched OFF
XE1 - switched ON
Vibration dose exposure time
XF
XFnn nn - time in minutes (0 ÷ 1440)
