181
SVAN 958A User Manual
in which 12 bits nnn denote the state of the markers:
b11 = state of #12 marker
b10 = state of #11 marker
...
b1 = state of #2 marker
b0 = state of #1 marker
B.16.3. Record with the breaks in the results registration
The record with the breaks in the results registration consists of four words:
<0xB0ii> <0xB1jj> <0xB2kk> <0xB3nn>
in which ii, jj, kk, nn bytes denote 4-bytes counter of left or skipped records: nnkkjjii (ii is the least significant
byte, nn - the most significant byte).
B.16.4. Record with the breaks account PAUSE in the results registration
The record with the breaks in the results registration consists of four words:
<0xA0ii> <0xA1jj> <0xA2kk> <0xA3nn>
in which ii, jj, kk, nn bytes denote 4-bytes counter duration of PAUSE in milliseconds:
nnkkjjii (ii is the least significant byte, nn - the most significant byte).
Pause duration means time passed between pressing <PAUSE> key and measurement continuation key. Start
delay after pressing continuation key isn't added to the counter.
B.17. CONTENTS OF THE FILES IN THE LOGGER CONTAINING TIME-DOMAIN SIGNAL
Records with samples and RPM value are kept in the logger file. The records with the state
of the markers, breaks in the results and pause are not saved in the file. Time-domain is saved when
the option LOGGER MODE in menu path: MENU / INPUT / LOGGER SETUP was set to the TIME value.
B.17.1. Samples record
Record form depends on the selection of channels, from which samples are saved, (path: MENU / INPUT /
LOGGER SETUP / CHANNEL x), state of the RPM measurement (path: MENU / INPUT / AUXILIARY SETUP
/ RPM SETUP / ENABLED:[
 ]) and RPM logging option (path: MENU / INPUT / AUXILIARY SETUP /
RPM SETUP / LOGGER: [
 ]) or MENU / INPUT / LOGGER SETUP / AUXILIARY / RPM:[  ]). The following
elements can be present (in the given sequence):
• Sample from the 1
st
channel if CHANNEL 1 was set to ON (path: MENU / INPUT / LOGGER SETUP
/ CHANNEL 1). The sample is written on three consecutive bytes from least to most significant byte.
• Sample from the 2
nd
channel if CHANNEL 2 was set to ON (path: MENU / INPUT / LOGGER SETUP
/ CHANNEL 2). The sample is written on three consecutive bytes from least to most significant byte.
