SVAN 958A User Manual
C.2. SPECIFICATION OF SVAN 958A AS VIBRATION LEVEL METER (VLM)
VLM function is provided by the BNC/IEPE inputs using the SC 61 TNC to BNC connector for Channel 4 and
cables providing LEMO 4-pins to 3 x BNC connection for Channels 1-3 or special cables dedicated for triaxial
accelerometers (e.g. SC 282S, SC 38).
Configuration of the complete VLM and its normal mode of operation
SVAN 958A sound & vibration analyser
3143M1 triaxial accelerometer, 100 mV/g (10 mV/ms
-2
)
,
3023M2 triaxial accelerometer, 10 mV/g (1 mV/ms
-2
)
,
SC 38 cable for the triaxial accelerometer (4 pin Microtech to LEMO 4 pin, 2.7 m)
Accessories included
SC 16 USB cable,
SC 61 integrated connector (TNC to BNC)
Accessories available
SV 111 Vibration Calibrator for HVM
SV 110 Vibration Calibrator
SA 17A External battery unit (6 x AA batteries) for the SVAN 95x instruments
SC 09A LEMO 1 pin to BNC cable, AC OUT cable
Note: System conforms to the ISO 8041-1:2016, ISO 2631-1:1997, ISO 2631-2:2003, DIN 45669-
1:2010 standards.
Normal operating mode
SVAN 958A in configuration with the supplied accelerometer with following settings: High or Low
measurement range (path: <Menu> / Channel Setup / Channel x – see Chapter 4.2)
Measured quantities
The measured quantities in the vibration meter mode are: RMS, VDV, OVL, PEAK, P–P, MTVV or MAX. The
definitions for mentioned parameters are given in Appendix D.
Additional features
• Overload indication
• Underrange indication
• Battery state indication
