SVAN 958A User Manual
B.7. STRUCTURE OF THE FILE CONTAINING LM RESULTS FROM LOGGER’S FILE
File header - cf. Tab. B.1.1.
Unit and software specification - cf. Tab. B.1.2.
Parameters and global settings - cf. Tab. B.1.3.
Hardware settings for channels - cf. Tab. B.1.4.
Software settings for channels - cf. Tab. B.1.5.
Trigger settings (cf. Tab. B.1.41, Tab.B.1.42).
Vector measurement settings - cf. Tab. B.1.6.
Header of the file from the logger - cf. Tab.B.1.22.
Contents of the file from the logger - cf. Tab.B.1.24.
File end marker - cf. Tab. B.1.25.
B.8. STRUCTURE OF THE FILE CONTAINING 1/1 OR 1/3 OCTAVE ANALYSIS RESULTS FROM
LOGGER’S FILE
File header - cf. Tab. B.1.1.
Unit and software specification - cf. Tab. B.1.2.
Parameters and global settings - cf. Tab. B.1.3.
Hardware settings for channels - cf. Tab. B.1.4.
Software settings for channels - cf. Tab. B.1.5.
Trigger settings (cf. Tab. B.1.41, Tab.B.1.42).
Vector measurement settings - cf. Tab. B.1.6.
Header of the file from the logger - cf. Tab.B.1.22.
Octave analysis header - cf. Tab.B.1.7.
Spectrum analysis header of the file from the logger - cf. Tab.B.1.23.
Contents of the file from the logger - cf. Tab.B.1.24.
File end marker - cf. Tab. B.1.25.
B.9. STRUCTURE OF THE FILE CONTAINING FFT ANALYSIS RESULTS FROM LOGGER’S FILE
File header - cf. Tab. B.1.1.
Unit and software specification - cf. Tab. B.1.2.
Parameters and global settings - cf. Tab. B.1.3.
Hardware settings for channels - cf. Tab. B.1.4.
Software settings for channels - cf. Tab. B.1.5.
Trigger settings (cf. Tab. B.1.41, Tab.B.1.42).
Vector measurement settings - cf. Tab. B.1.6.
Header of the file from the logger - cf. Tab.B.1.22.
FFT analysis header - cf. Tab.B.1.8.
Spectrum analysis header of the file from the logger - cf. Tab.B.1.23.
