B.4 STRUCTURE OF THE FILE WITH 1/1 OCTAVE ANALYSIS RESULTS
File header - cf. Tab. B.1.1.
Unit and software specification - cf. Tab. B.1.2.
Parameters and global settings - cf. Tab. B.1.3.
Hardware settings for channels - cf. Tab. B.1.4.
Software settings for channels - cf. Tab. B.1.5.
Trigger settings (cf. Tab. B.1.41, Tab.B.1.42).
Vector measurement settings - cf. Tab. B.1.6.
Octave analysis header - cf. Tab.B.1.7.
Settings for vibration dose measurement (the presence depends on the MEASURE DOSE and channel filter
settings) - cf. Tab. B.1.9.
Main results - cf. Tab. B.1.10.
RPM results (present if RPM measurement was enabled) - cf. Tab. B.1.34.
SEAT measurements settings (cf. Tab. B.1.36).
Selected statistical levels in channels - cf. Tab. B.1.11.
One-channel 1/1 Octave analysis results (one for each channel with spectrum analysis enabled) - cf. Tab.
B.1.12.
TOTALS description (if needed) - cf. Tab. B.1.16.
Description of user-defined filter (if needed) - cf. Tab. B.1.17.
Maximum 1/1 Octave analysis results in one channel (one for each channel with spectrum analysis
enabled, presence depends on the MAX. SPECT. setting) - cf. Tab. B.1.37.
Minimum 1/1 Octave analysis results in one channel (one for each channel with spectrum analysis enabled,
presence depends on the MIN. SPECT. setting) - cf. Tab. B.1.38.
Peak results coming from 1/1 OCTAVE analysis (one for each channel with spectrum analysis enabled ) -cf.
Tab. B.1.46.
Header of the statistical analysis in channels (the presence depends on the SAVE STAT. setting) - cf. Tab.
B.1.18.
Results of the statistical analysis in one channel (the presence depends on the SAVE STAT. setting) - cf. Tab.
B.1.19.
Results of the statistical analysis performed in 1/1 Octave mode (the presence depends on the SAVE STAT.
setting) - cf. Tab. B.1.20.
File end marker - cf. Tab. B.1.25.
B.5. STRUCTURE OF THE FILE WITH 1/3 OCTAVE ANALYSIS RESULTS
File header - cf. Tab. B.1.1.
Unit and software specification - cf. Tab. B.1.2.
Parameters and global settings - cf. Tab. B.1.3.
Hardware settings for channels - cf. Tab. B.1.4.
Software settings for channels - cf. Tab. B.1.5.
Trigger settings (cf. Tab. B.1.41, Tab.B.1.42).
Vector measurement settings - cf. Tab. B.1.6.
Octave analysis header - cf. Tab.B.1.7.
