All available measurement results can be stored in the internal FLASH type memory of the instrument (32 MB)
or on the external USB Memory Stick.
The internal memory of the instrument is divided into two separate parts. One part is dedicated
for saving the result and setup files and its size is equal to 16 121 360 bytes. The second part is used
for saving the logger files and its size is equal to 15 728 156 bytes. To save a result file the user
has to choose one of the available options: Save / Auto Name (path: <Menu> / File / Save) or pressing
<ENTER>
and <
Alt>
together), Save
/ F
ile Name
(path: Menu / File / Save) or pressing <ENTER>
and <Alt
>
together), Auto Save (path: <Menu> / File / Save Options ) or Direct Save (path: <Menu> / File / Save Options
). To save a setup file the user has to choose Save Setup option from the File list. The logger files are created
automatically (the usage of the Save is not required). The scheme of the instrument’s memory organisation is
presented below.
The instrument supports several file types: for main results, for logger results, for wave and for the instrument
settings. More detailed the file sytem of the instrument is described in the File menu chapter.
Note: The instrument’s logger memory is independent from the results and setup memory. The
capacity of the available memory is equal to 32 MB and is divided between logger
(15 728 156 bytes) and results and setup settings (16 121 360 bytes).
