SVAN 958A User Manual
A.3. FUNCTION #2 – READ-OUT OF THE MEASUREMENT RESULTS IN THE SLM OR VLM MODE
Function #2 enables one to read out the current measurement data in the SLM or VLM Mode.
Note: This function can also be programmed while measurements are taking place.
In this case, the values measured at the moment of command execution will be sent out.
#2 function has a format defined as follows:
#2,t,p,X?,X?,X?,(...),X?;
where:
t - result timestep code. Can be one of:
s 100ms
l logger step
c 1s
If no code is provided, current measurement time is assumed
X - the code of the result,
p - the number of the results set
0 – for reading vibration dose results
1,2,3,..,12 – for reading profile results
(calculated from the formulae: ChannelNumber + 4 * (ProfileNumber - 1)
The results timestep codes are defined as follows:
Note: After entering the STOP condition, #2 function is no longer active and has to be
reprogrammed in order to read-out successive measurements.
The instrument will send the values of the results in the format defined as follows:
#2,p,Xccc,Xccc,Xccc,(...),Xccc; (where p - the number of the results set)
or
#2,?; (when the results are not available).
The codes of the results in the case of SLM mode are defined as follows:
T time of the measurement (ccc – value in seconds);
V the overload flag (ccc equals to 0 or 1);
P the PEAK value (ccc – the value in dB);
M the MAX value (ccc – the value in dB);
N the MIN value (ccc – the value in dB);
S the SPL value (ccc – the value in dB);
R the LEQ value (ccc – the value in dB);
U the SEL result (ccc – the value in dB);
